Stainless Steel Rotary Industrial Drying Equipment For Copper Concentrate
Stainless Steel Rotary Industrial Drying Equipment For Copper Concentrate
Specifications
Brand Name :
Lipu
Model Number :
HG1×10
Certification :
ISO9001:2008,CE,IQNet
Place of Origin :
China
MOQ :
1set
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30sets/quarter
Delivery Time :
15-20 days
Packaging Details :
Container
Product Name :
Stainless Steel Rotary Industrial Drying Equipment
Model :
HG1×10
Shell diameter(mm) :
1000
Shell length(mm) :
10000
Shell volume(m³) :
7.9
Rotary speed(r/min) :
1-8
Power :
5.5kw
Application :
sludge, coal, sand, animal dung, fly ash, clay, coal slime, etc.
Condition :
New
Color :
According to Customer
Description

Stainless Steel Rotary Industrial Drying Equipment For Copper Concentrate

Equipment Introduction :
Stainless steel rotary industrial drying equipment is traditional and reliable drying equipment, the

material will be lifted up and fallen down by the lifting plates inside of the cylinder while the cylinder is

rotating, the moisture in the material is continuously evaporated when the material contacts with the hot

wind inside of the cylinder, to achieve the purpose of drying materials. It is suitable for drying sludge,

coal, sand, animal dung, fly ash, clay, coal slime, ore, steel slag, quartz sand, kaolin clay, bentonite,

sawdust, desulfurization gypsum, compound fertilizer,etc.

Performance Characteristics :

1. The operation parameters can be changed according to the different material properties, the material

in the dryer cylinder can form stable material curtain, to make the heat exchange more fully;

2. Stainless steel rotary industrial drying equipment can prevent from acid/alkali corrosion and iron

contamination;

3. The adjustable stainless steel plates’ sealing are adopted at the connection of the feeding and

discharging devices, it’s with good sealing property, which greatly reduces the thermal losses inside of

the cylinder, so as to directly reduce the fuel consumption;

4. Counterflow drying method, it can obtain higher evaporation intensity; downstream drying method and

indirect drying method are suitable for drying materials which are sensitive to temperature;

5. Fuel can be diesel oil, heavy oil, and natural gas, gas, coal, electricity and biomass particles for

environmental protection.

Technical Data:

Model Shell diameter(mm) Shell length(mm) Shell volume(m³) Rotary speed(r/min) Power(kW)
HG0.6×6 600 6000 1.7 1-8 3
HG0.8×8 800 8000 4 1-8 4
HG1×10 1000 10000 7.9 1-8 5.5
HG1.2×6 1200 6000 6.8 1-6 5.5
HG1.2×8 1200 8000 9 1-6 5.5
HG1.2×10 1200 10000 11.3 1-6 7.5
HG1.2×11.8 1200 11800 13.4 1-6 7.5
HG1.5×8 1500 8000 14.1 1-5 11
HG1.5×10 1500 10000 17.7 1-5 11
HG1.5×11.8 1500 11800 21 1-5 15
HG1.5×15 1500 15000 26.5 1-5 15
HG1.8×10 1800 10000 25.5 1-5 15
HG1.8×11.8 1800 11800 30 1-5 18.5
HG1.8×15 1800 15000 38.2 1-5 18.5
HG1.8×18 1800 18000 45.8 1-5 22
HG2.2×11.8 2200 11800 44.8 1-4 22
HG2.2×15 2200 15000 53.2 1-4 30
HG2.2×18 2200 18000 68.4 1-4 30
HG2.2×20 2200 20000 76 1-4 30
HG2.4×15 2400 15000 67.9 1-4 30
HG2.4×18 2400 18000 81.4 1-4 37
HG2.4×20 2400 20000 90.5 1-4 37
HG2.4×24 2400 24000 108.6 1-4 45
HG2.8×18 2800 18000 110.8 1-3 45
HG2.8×20 2800 20000 123.2 1-3 55
HG2.8×24 2800 24000 147.8 1-3 55
HG2.8×28 2800 28000 172.4 1-3 75
HG3×20 3000 20000 141.4 1-3 55
HG3×24 3000 24000 169.7 1-3 75
HG3×28 3000 28000 198 1-3 90
HG3.2×24 3200 24000 193 1-3 90
HG3.2×28 3200 28000 225.2 1-3 90
Product Picture Show :
Stainless Steel Rotary Industrial Drying Equipment For Copper Concentrate
