Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck
Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck
Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck
Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck
Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck
Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck
Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck
Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck
Specifications
Brand Name :
HOWO
Model Number :
HOWO
Certification :
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Place of Origin :
China
MOQ :
1UNIT
Price :
NEGOTIABLE
Payment Terms :
L/C,T/T
Supply Ability :
400 units/month
Delivery Time :
40 worker days
Packaging Details :
Nude
Product name :
6*4 water tanker truck
Volume :
15001 - 30000L
Sprinkling Area :
Sprinkling Area
Engine Type :
Wd615.95
Engine Capacity :
＞8L
Fuel Tank :
400L
Transport Package :
Sea- Standard Package
HS Code :
8703109000
Description

Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck for sale


Water Tank Truck: Your Fun and Functional Friend!
Hey there, get ready to dive into the exciting world of water tank trucks!
These awesome machines, also known as sprinklers, water tankers, sprayers, or street washers, are like the superheroes of our streets. They play a big role in keeping our roads clean, our plants happy and hydrated, our buildings looking fresh, and even help put out fires when needed.
Each water tank truck is equipped with a special fire interface, turning it into a temporary emergency fire sprinkler. Like a powerful beast, the vehicle's engine powers a gearbox. A power take-off (PTO) on the gearbox drives the sprinkler pump, which is like the heart of the operation. This pump generates the main force to propel the liquid from the tank through the pipe network.
The truck can self-prime up to a height of 7 meters. Its sprinkler width reaches up to 20 meters, and it can spray as far as 28 meters. You can adjust the spray into a columnar shape for long-distance reach or a mist shape for shorter, gentle coverage. The design typically features front spraying and rear sprinkling functions. The front is equipped with a duck-shaped nozzle or a round-headed flushing nozzle, while the rear has a cylindrical sprinkler nozzle or shower a nozzle. A working platform at the rear is fitted with a high-pressure water cannon. Additionally, the rear can optionally be equipped with 8 nozzles.
The pipeline system comprises pipes, four-position three-way ball valves, straight-through ball valves, filters, and water outlets. These water outlets include front flushing, rear sprinkling, and side spraying functions. It also features high-position side sprinklers and a rear working platform with a greening sprinkler cannon.
The cab of a water tank truck comes in two main types: pointed cab (long-head cab) and flat cab (short-head cab). Primarily used for street washing, dust removal, and cooling, the truck allows you to adjust the sprinkler nozzle's thread to change the spraying direction and angle. The cannon can be utilized for urban and rural landscaping as well as emergency firefighting. Meanwhile, the shower head is designed to irrigate the dust collected by the sprinkler in the middle of the road, helping to cleanse the air.
So, next time you see a water tank truck, remember it's not just a vehicle—it's a fun and functional friend making our world a cleaner and better place!

Sinotruk HOWO 4*2 6X4 20000 Liters Water Tanker Mini Truck

Overview
Driving type 6*4 LHD Driving form
Horsepower 336HP
Transmission Type Manual
Fuel Type Diesel
Gross Vehicle Weight(kg) 25000kg
Brand Name SINOTRUK -HOWO
Truck type ZZ1257N4641W
Condition New
Emission Standard EURO 2
Horse Power 336HP
Engine Capacity 247
Water tank capacity 20m³
Place of Origin Shandong,China(Mainland)
vehicle size 10350mmx2496mmx3050mm
Driving type Left hand driving
1,Basic Vehicle Information
Color White, green, orange, red, color can be selected
Approaching angle/Departure angle(°) 19/23
Wheel base (mm) 3425+1350
Axle number 3
Drive shaft Second and third axes
Gross Vehicle Weight(kg) 25000
2,Engine
Engine type WD615.95
Horse Power 336HP
Vehicle torque(N-m) 1350N.m
Maximum Torque and Speed 1100-1600rpm
Rated speed 2200rpm
Engine type Inline six-cylinder, water-cooled, four-stroke, supercharged intercooler, high pressure common rail, SCR
Emission Standard EURO 2
Engine power(kw) 247kw
Engine weight(kg) 850kg
Number of engine cylinders 4
3,Transmission
Transmission HW19710
4,Vehicle chassis
Allowable Load of Front Bridge(kg) 9000
Allowable Load of Rear Bridge(kg) 16000
Fuel tanker capacity(L) 300
ABS Optional
Tyre type 12.00R20
Tyre number 10+1,Plus a spare tire
Types of lifting transportation Hydraulic front support
Front axle type HF9
Rear axle type HC16
Rear axle ratio 5.7
Cab Passenger Number 3
Cab type HW76
Air conditioning YES
Frame type 8+8/300
ABS NO
5,Water tank parameters
Water tank capacity 20m³
Tank thickness 5mm
Tanker dimension 7650mmx2326mmx1450mm
