Engine

Engine model: YN4102QBZL,EuroⅡemission standard

Clutch

Single-plate diaphragm spring clutch, diameter 300 mm, hydraulically operating

Transmission

WLY transmission, model WLY646,synchromesh,6 forward & 1 reverse
Ratio:6.314 3.913 2.262 1.393 1 0.788 5.874 (R)

Front Axle

VGD027QB, forging forming of front axle I-beam, to guarantee the stiffness and high strength.

Rear Axle

HGC055QJ,mature punching welding axle and pressed axle housing
Ratio:4.63

Chassis

Frame :ladder frame with section of 215×70×6 mm, all cold riveted cross members

Steering

LG9704470020,hydraulic steering with power assistance
Ratio: 18.85:1

Brakes

Service brake: dual circuit compressed air brake
Parking brake (emergency brake):spring energy, compressed air operating on rear wheels (optional)
Auxiliary brake: engine exhaust brake (optional)

Wheels & Tyres

Rims: 6.00G-16,6 hole-steel
Tyres:8.25-16 tube
Option:7.50-16 tube, 7.50R16 tube, 8.25R16 tube

Driver’s Cab

Single cab, 45° hydraulically tiltable to the front,2-arm windscreen wiper system with three speeds, adjustable driver’s seat,
with heating and ventilating system, interior double sun visor, sunroof, radio and USB interface, safety belts, adjustable
steering wheel, horn.

Electrics

Operating voltage:24 V, negative grounded

Instrument Panel

Active check central controller with indicators, with this integral instrument the daily manual checks on the vehicle and combined
indicators of compressed air pressure, coolant temperature, engine oil pressure.

Dimensions in mm

Overall dimension(L x W x H mm) 6995×2180×2450
Body size 5150×2050×550

Weight in kg

Dead weight (kg) 3500
Load weight(kg) 7000
Gross vehicle weight (kg) 10500

Performance

Maximum driving speed(km/h) 95
Maximum grade ability(%) 30
Minimum ground clearance(mm) 210
Minimum turning circle(m) 15.5
Fuel consumption(1/100km) 14.5
