Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Mini Gold Trommel Wash Plant 1-5t/H For Mineral Separation
Specifications
Brand Name :
KEDA
Model Number :
KDTJ-5
Place of Origin :
SHANDONG, CHINA
MOQ :
1SET
Price :
USD5000/SET
Payment Terms :
L/C, T/T
Supply Ability :
1000SET per year
Delivery Time :
15days
Name :
Mini Gold Wash Plant
Work Capacity :
1-5t/h
Application :
Mineral Separation
Type :
Gravity Separator
Applicable Industries :
Energy & Mining
Warranty :
1Year
Description

Mini Small Portable Gold Wash Plant Gold Washing Plant Machine

Trommel Screen Good Price For Sale Australia

1.Description

1). Portable placer mining plant 's widely used for portable gold rush plant
2). Easy to move,because of the small volume.
3). Feeding by manual.
4). High capacity and high power scrubbing, large capacity can reach 200-220tons per hour
5). The long drum of the scrubber retains material for longer, more vigorous washing for complete separation
6). One high output electrical motor driving a gear system providing efficient torque
7). Adjustable rotary speed
8). The water with high pressure flushed the inwall of drum
9). Can accept material up to 230mm
10). Mechanical sealing of inlet chute - minimal spillage when over feeding
11). Drive loads absorbed within the drive frame and pivoting drive frame design - Foundations only have to support vertical load and are not critical for alignment ie minimal cost
12). Shell design less mass than conventional roller supported units - installation craneage requirement reduced

Mini Gold Trommel Wash Plant 1-5t/H For Mineral SeparationMini Gold Trommel Wash Plant 1-5t/H For Mineral SeparationMini Gold Trommel Wash Plant 1-5t/H For Mineral Separation

2. Information

Model KDTJ-10 Gold Trommel KDTJ-5 Gold Trommel
Machine size(mm) 2900 *1200*1500 2800*1350* 1150
Processing capacity 5-10t/h 1-5t/h
Screen 　
Screen size (mm) 530(Dia.)*1800(Length) 400(Dia.)*1300(Length)
Mesh 8mm 8mm
Driven type by belt by belt
Diesel engine Portable Diesel Engine Portable Diesel Engine
　 　
with CE Certificate with CE Certificate
Oil Tank 2.5L 2.5L
Feeder hopper(mm) 1200*810 1066*568
Gold Felt 　
rough gold felt(mm) 2000*600(1pc) 1500*400(1pc)
fine gold felt(mm) 2000*600(1pc) 1500*400(1pc)
Water pump 2inch with water pipe 2inch with water pipe
Product tags

mineral separation plant

,

gold wash plant

,

alluvial gold washing plant
