Specifications
Brand Name :
keda
Model Number :
kdtj
Certification :
iso9001
Place of Origin :
China
MOQ :
1set
Price :
$18500/set
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100sets/month
Delivery Time :
30days
Packaging Details :
in container
Name :
Mini Trommel Wash Plant
usage :
gold mining
Color :
clients' request
keyword :
gold trommel
keyword1 :
gold trommel screen
Size (L*W*H) :
2000*2200mm
Description

keda gold and diamond mining equipment gemstone gold wash plant trommel mini with long clay scrubber

1. Features of Gold Mining Trommel Machine from KEDA

1) The KD-TJ series gold washing plants are designed according to your specific mining conditions and requirements.
2) Feeding system with hopper feeder(Surface Color is customized), water spray pipes inside the hopper for spray waters to the soils.
3) Heavy duty clay scrubber with inside high pressure water spray pipes for breaking off hard clay. (if required)
4) At least Double sieve trommel screen with NSK bearings(Or any other famous and qualified bearing as our clients wanted) and high pressure water spray pipes on both sides for washing, screening and separating.
5) Double gold recovery systems to ensure highest recovery rate of gold (up to 98%).
6) Water supplying systems with multiple sets of big power submersible slurry pumps, hoses, valves, etc.

Basic parameters

Model KDTJ-50 KDTJ-100 KDTJ150
SIZE/mm 7000*2000*3000 8300*2400*4700 9800*3000*5175
Capacity 80-100 tph 200-300 tph 300-400 tph
Power 50 kw 100 kw 150 kw
Feeder Hopper/mm 2000*2200 3000*2200 800*3000
Sluice Box 1set 2set 3set
Recovery Rate 98% 98% 98%

KDTJ-50 KDTJ-100 KDTJ-200
Performance
Dimension(L*W*H)(mm) 7000*2000*3000 8300*2400*4700 9800*3000*5175
Processing capacity (t/h) 30-50 100-150 200-300
Main Power
Power(kw) 75 100 150
Feeder hopper Gold screen machine
Size (L*W*H) 2000*2200mm 3000*2200mm 3800*3000mm
Gold chutes with carpet
Size (W*L) 1000*2000mm 1000*6000mm 1000*6000mm
Quantity 2 2 3
Water system
Pump power(kw) 7.5 22 30
Optional equipment

Wheel, Grizzly, conveyor, shaking chute , centrifugal machine etc.

2000*2200 Mini Trommel Wash Plant2000*2200 Mini Trommel Wash Plant2000*2200 Mini Trommel Wash Plant2000*2200 Mini Trommel Wash Plant2000*2200 Mini Trommel Wash Plant2000*2200 Mini Trommel Wash Plant


2000*2200 Mini Trommel Wash Plant2000*2200 Mini Trommel Wash Plant2000*2200 Mini Trommel Wash Plant

Our service

1.-- will provide 12-months for the quality of the diesel engines, generators, gear boxes, hydraulic system, control system for free.
-- Longlife warranty with charging.
--Wearing parts are not included.

2.---24hours after sales service.

3.---Engineer is available to go aboard to conduct the installation and train operators

4.---We have experienced and qualified technicists and engineers who can design rational and feasible solutions according to clients’ requirements and the working condition.

Company Certificate

1.--ISO9001:2008 International Quality Certificate

2.--National design patent and utility Patent

3.--Authority supply

3.--Credit authorization

2000*2200 Mini Trommel Wash Plant2000*2200 Mini Trommel Wash Plant

Our Product Video WEBSITE

Company Introduction Video https://youtu.be/uIuRcg6Syxs
Gold /diamomd wash plant working video https://www.youtube.com/watch?v=JRSRUSVyCbY
Movable Gold /diamond Mining Equipment https://www.youtube.com/watch?v=m4kFpJ8UQqA
Keda 100-150t/h gold /diamond mining trommel https://www.youtube.com/watch?v=AeG0tR6xxVs
Keda 50-80t/h gold/diamond mining trommel https://www.youtube.com/watch?v=Prya0GmGPHY
Vibration Screen for Gold Mining https://www.youtube.com/watch?v=yoluqw36pZQ
Mini Gold Trommel Being tested in factory https://www.youtube.com/watch?v=p_1nuQAl08c
Keda Mini Gold Trommel with ISO 9001 https://www.youtube.com/watch?v=qrGWRmdxxFEQingzhou
Mini Dry Air Extraction Machine https://www.youtube.com/watch?v=ZhOchMKtlF8
