Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Land 300cbm/H Cutting Suction Dredger With Dredging Dragon Machine
Specifications
Brand Name :
KD-headdredging
Model Number :
300
Certification :
ISO9000
Place of Origin :
China
MOQ :
1 unit
Price :
USD20000 /unit
Payment Terms :
T/T
Supply Ability :
1 unit per month
engine :
Weichai,Yuchai
propulsion :
spud
Type :
Cutter Suction Dredger,sand dredger
Power type :
Diesel,Electric,no motor
Warranty :
12 months
After-sales service provided :
Field installation,Video technical support
Description

Heavy Duty Cutter Suction Dredger With Mud And Stone Dredging Dragon machine

Dragon Machine for River bed dredging project

Cutter suction dredger for land reclaim

1. Dredging depth 10-12 m

2. Capacity: 200-300 cbm soli per hour

3. Engine : diesel engine

Product Application

Cutter Suction Dredger is a special dredging machine with ISO9001:2008. Cutter Suction Dredger is flexible to most kinds of geologic structures and has a lot of obvious advantages:

1) Wide application range: It can be widely used for mining, sand production, reclamation construction, desalting, land reclamation and so on.

2) High efficiency: The max output can reach to 700 m³/h, water flow 800-5000 steer per hour, digging depth is 4-15 meters, and discharge distance is 200-1500 meters.

3) Quick return, high profits: usually, the investor can Achieve profitability within half a year. It is highly efficient with low cost, a good underwater dredging machine.

4) Standard quality: the main body of the machine is strong, durable and low failure rate.

Other Models

Model HDCSD150
(6inch)		 HDCSD200
(8inch)		 HDCSD250
(19inch)		 HDCSD300
(12inch)		 HDCSD350
(14inch)		 HDCSD450
(18inch)		 HDCSD500
(20inch)		 HDCSD600
(24inch)
Dimensions(L*W*H)m 25*4.7*1.26 26*5.3*1.5 32.5*5.3*1.5 33*6.6*1.8 35*6.8*2 37*7.9*2.2 39*9*2.5 42*10*2.8
Design draught 0.8m 1.0m 1.0m 1.2m 1.4m 1.6m 1.9m 2.2m
Standard dredging depth 12m 12m 15m 15m 15m 15m 15m 15m
Cutter power 25kw 40kw 58kw 88kw 88kw 180kw 280kw 400kw
Total weight 29mt 38mt 55mt 82mt 110mt 155mt 210mt 300mt

Remarks:The above parameter are standard models,the dredger is Customized according to requierements,any question,please email me or call me for further talking.

Advantages


1. One-man operation.
2. New highly effective cutter /wheel drive system
3. Reliable hydraulic system.
4. Fresh water cooling system
5. Completely assembled and fully tested before delivery
6. Very simple and fast assembly with experienced engineers.
7. Standard design, allowing short delivery times
8. Standard spare parts available from stock
9. Designed as standard to qualify for Coastal Waters Certificate
10. Customized according to customer's working conditions
