Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge
Specifications
Brand Name :
MF
Model Number :
MF-LI-B2-D
Certification :
CCC, CE, EMC, ETL, GS, RoHS, SAA
Place of Origin :
China
MOQ :
1PCS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
5000pcs/months
Delivery Time :
7 weeks days
Packaging Details :
254× 90× 210
Light Source :
LED
Available Colors :
Red(Other Color Is Optional
Intensity :
≥32.5CD(Type B),Others Optional(10CD, 100CD,etc
Horizontal Output :
360
Vertical Divergence :
≥10
Flash Characteristics :
Steady-Burning/20/30/60 Adjustable
Working Mode :
Main & Stand by(Other Modes Are Optional)
LED Life :
Eration as Option. LED Life Experience(Hours) >100
Operating Voltage :
DC(48VDC) &AC(110-240VAC) or Others
Power :
5W
Circuit Protection :
Integrated
Body Material :
Polycarbonate
Base Material :
Die-Casting Aluminum
Description

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Features:

1. High reliability

Automatic switching of main and backup lamps to ensure continuous marking.

Lightning protection, in accordance with IEC standard.

Integrated circuit protection against abnormalities.

2. Strong environmental adaptability

IP66 waterproof rating.

Operating temperature -40ºC to 65ºC, storage temperature -55ºC to 70ºC.

Resistant to wind speed up to 240km/h.

3. Flexible Design

Support DC48V and AC110-240V power supply.

Built-in light control, automatic switching.

Multiple mounting methods for ease of use.

Key Advantages:

1. High Reliability

Main & standby mode ensures continuous operation.

Built-in surge protection.

Long LED life (>100,000 hours).

2. Durability

IP66 waterproof rating.

UV-resistant polycarbonate cover.

Corrosion-resistant die-casting aluminum base.

3. Adaptability

Dual power supply (DC & AC).

Automatic day/night operation.

Optional GPS sync and solar power.

Specifications

Light Source LED
Available Colors Red (Other color is optional)
Intensity (cd) ≥32.5cd (type B), others optional (10cd, 100cd, etc)
Horizontal Output (degrees) 360
Vertical Divergence (degrees) ≥10
Flash Characteristics Steady-burning/20/30/60 adjustable
Working Mode Main & stand by (other modes are optional)
Operation Mode Dusk-to-dawn Automatically as standard. 24 hours operation as option.
LED Life Experience (hours) >100,000
Operating Voltage DC(48VDC) & AC(110-240VAC) or others

Power (W) 5
Electrostatic IEC61000-4-2 Contact discharge 8kV
Circuit Protection Integrated
Body Material Polycarbonate
Base Material Die-casting aluminum
Mounting 3/4 inch pipe thread or D140mm×M10*3
Dimension (mm) 254×90×210 or 254×165×250
Weight (kg) 1.5 or 2
Product Life Expectancy 10 years plus

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

Main-Standby Adjustable Wide Voltage Input UV-Resistant Polycarbonate IP66 Low-Intensity Dual-Lamp Aviation Obstacle Obstruction Light For Bridge

SERVICE
Ming Feng lighting CO.,Ltd providing the OEM & ODM service for all the partners all around the world, Our LED light is in high quality standard at reasonable and competitive price, our designer and engineer help our LED light in tasteful design and excellent performance.We are able to offer our valuable clients:
★ OEM/ODM Serivce
★ Photometric/IES file
★ Dialux simulation design
★ PCB Design/Driver Design
★ Heat Management/Optical Design
★ Industry Design
★ Market Support
★ 3D Printing
★ Multiple Listing/Private Label.
