Specifications
Brand Name :
Minfeng
Model Number :
Solar Cable
Certification :
ISO,CE,IEC,TUV,KEMA
Place of Origin :
Hebei, China
MOQ :
100
Price :
0.1-5
Payment Terms :
L/C,T/T
Supply Ability :
100KM/Week
Delivery Time :
10 Days
Free Sample :
Avaliable
Rate Voltage :
1KV AC 1500V DC
Insulation :
XLPO
Male End Type :
CEE, CEE/16 3 Prong Schuko Plug
Trademark :
Minfeng
Condutor :
tinned copper
Description
TUV 2 PfG 1169 Pv1f 4mm 6mm2 10mm Twin Core Solar Copper Wire Cables DC PV Cable
PV1-F-06/1KV Photovoltaic Cable

PV1-F photovoltaic cable is a specialized cable designed for solar photovoltaic module systems. It features exceptional weather resistance, high temperature tolerance, and friction resistance, ensuring long service life and reliable performance.

Constructed with high-quality oxygen-free tinned copper conductors for superior conductivity, these cables utilize high-performance insulating and sheath materials that undergo radiation cross-linking via high-energy electron accelerators, providing reliable insulation and mechanical properties.

PV1-F Cable Specifications
Model: PV1-F Outer diameter of conductor stranded: 2.60mm
Application standard: 2 PfG 1169/08.2007 Insulation nominal thickness: 0.8mm
Conductor material: IEC 60228, Category 5 stranded tinned copper wire Sheath Nominal Thickness: 0.9mm
Insulation material: Irradiation cross-linked low-smoke halogen-free flame-retardant polyolefin Outer diameter of finished wire: 6.1±0.1mm
Sheath material: Radiation cross-linked low-smoke halogen-free flame-retardant polyolefin Conductor resistance (20ºC): ≤5.09Ω/km
Nominal cross section: 4mm² 6mm² Working environment temperature ºC: -40~+90
Current carrying capacity: 5 high Higher conductor temperature: +120ºC
Number of cores: 1 Reference short-circuit allowable temperature: 200ºC 5S
Conductor structure: NO./mm 56/0.30 Rated voltage: DC: 1.8kv AC U./U: 0.6/1kv

Key Features & Advantages: PV1-F cable offers superior resistance to UV radiation, heat, cold, ozone, water, acid, salt corrosion, along with excellent wear resistance and weather capability.

4mm 6mm 10mm Twin Core Solar PV Cable TUV 2 PfG 1169 Pv1f For Photovoltaic Systems 4mm 6mm 10mm Twin Core Solar PV Cable TUV 2 PfG 1169 Pv1f For Photovoltaic Systems 4mm 6mm 10mm Twin Core Solar PV Cable TUV 2 PfG 1169 Pv1f For Photovoltaic Systems
1500V Photovoltaic Cable H1Z2Z2-K

H1Z2Z2-K 1500V DC photovoltaic cable is designed for use in nominal 1.5KV DC voltage photovoltaic power generation systems between conductors and between conductors and ground. This represents an upgraded product based on the original PV1-F-06/1KV photovoltaic cable, offering enhanced anti-aging performance.

H1Z2Z2-K Cable Specifications
Conductor section: 0.5mm²-300mm² (custom specifications available) Ambient temperature: -40℃ to +90℃; -40 to +194
Conductor: Tinned copper stranded wire conforms to EN60228.5 category soft conductor Maximum short-circuit temperature: 280°C, +536°F
Insulation: Low-smoke halogen-free radiation crosslinked polyolefin Bending radius: Fixed installation>4x; Mobile installation>5x
Sheath: Low-smoke halogen-free radiation crosslinked polyolefin Material characteristics/standards: Fire performance: EN 60332-1-2:2004; Zero smoke emission: IEC61034: minimum 60% light transmittance
Rated voltage: DC 1.5/1.5kV AC 1.0KV Low fire load: DIN 51900
Test voltage: 6500V, 50HZ, 5 minutes Certification: EN50618:2014
Temperature class: -45℃ to 125℃; -45 to +257 Application standard: EN50618:2014
4mm 6mm 10mm Twin Core Solar PV Cable TUV 2 PfG 1169 Pv1f For Photovoltaic Systems 4mm 6mm 10mm Twin Core Solar PV Cable TUV 2 PfG 1169 Pv1f For Photovoltaic Systems 4mm 6mm 10mm Twin Core Solar PV Cable TUV 2 PfG 1169 Pv1f For Photovoltaic Systems
Product Technical Parameters
Single Core PV1-F Solar Cable
Cross Section (mm²) Conductor Construction (n/m) Conductor OD (mm) Cable Outer (mm) Resistance Max. (Ω/km) Current Carrying Capacity (A) Insulation Min.Wall Thickness (mm) Sheath Min.Wall Thickness (mm)
1x1.5mm²30/0.251.584.9013.30300.670.73
1x2.5mm²50/0.252.025.457.89410.670.73
1x4mm²56/0.32.606.104.75500.670.73
1x6mm²84/0.33.427.203.39700.80.80
1x10mm²142/0.34.569.001.95980.90.90
1x16mm²228/0.35.6010.201.241321.000.90
1x25mm²361/0.36.9512.000.7951761.190.92
1x35mm²276/0.408.7413.82181.201.00
Twin Core PV1-F Solar Cable
Cross Section mm² Conductor Construction (n/mm) Conductor OD (mm) Cable Outer (mm) Resistance Max. (Ω/km) Current Carrying Capacity (A)
2 x 1.5mm²30/0.251.588.3 ± 0.213.3030
2 x 2.5mm²50/0.252.029.2 ± 0.27.9841
2 x 4mm²56/0.32.6012.0 ± 0.24.7550
2 x 6mm²84/0.33.4213.5 ± 0.23.3970
2 x 10mm²142/0.34.5617.6 ± 0.21.9598
2 x 16mm²228/0.35.6019.8 ± 0.21.24132
Additional Options Available: We offer other models and sizes beyond those listed. Please contact us for specific requirements or custom specifications.
