Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
Specifications
Brand Name :
Minfeng
Model Number :
Solar Cable
Certification :
ISO,CE,IEC,TUV,KEMA
Place of Origin :
Hebei, China
MOQ :
100
Price :
0.1-5
Payment Terms :
L/C,T/T
Supply Ability :
100KM/Week
Delivery Time :
10 Days
Free Sample :
Avaliable
Rate Voltage :
1KV AC 1500V DC
Insulation :
XLPO
Male End Type :
CEE, CEE/16 3 Prong Schuko Plug
Trademark :
Minfeng
Condutor :
tinned copper
Description
Solar Cable Twin Double Dual 2*2.5MM² 2*4MM² 2*10MM²

High-performance photovoltaic cables designed for solar power systems, industrial applications, power stations, and construction projects.

Technical Specifications
Rated Voltage 1000V, 1.5kV
Available Sizes 2.5mm² - 10mm²
Conductor Material Tinned copper
Insulation Material XLPO
Jacket Material XLPO
Rated Current 16A, 20A, 25A, 30A, 40A, 50A, 60A
Temperature Rating 125℃
Maximum Short-Circuit Temperature 250℃
Product Lifespan 30 Years
Standard TUV
Performance Characteristics
  • Dielectric strength: DC-15KV/1 sec MIN
  • Spark test: DC-10KV/In the air
  • Weathering/UV-resistance: 720h, No cracking
  • Elongation of unaged values: ≥125%
  • Tensile strength of unaged values: ≥6.5
  • Elongation after aging: ≥70%
Product Details
Model Number Solar Cable / Twin core Photovoltaic Cable PV1-F / H1Z2Z2-K
Brand Name Minfeng
Color Red Black
Wire Size 2*2.5mm² / 2*4mm² / 2*6mm²...
Rated Temperature -45°C to 90°C
Rated Voltage AC: 0.6-1.0kV / DC: 1.0-1.8kV
Bending Radius 5* overall diameter
Maximum Conductor Temperature +120°C (for 20000h)
Life Period >30 years
Place of Origin Hebei, China
Product Gallery
Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation Photovoltaic Twin Core Solar Cable With Tinned Copper Conductor XLPO Insulation
