26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
Specifications
Payment Terms :
L/C,T/T
Cores No :
1-5
Delivery Time :
10 Days
Supply Ability :
100KM/Week
Core Mark :
Number or Color Strip
Outer Sheath Color :
Black or as per required
Place of Origin :
Hebei, China
Model Number :
high voltage power cable
Certification :
ISO,CE,IEC,TUV,KEMA
Brand Name :
Minfeng
Insulation :
XLPE
Flame Retardant :
Available
Type :
YJV YJV22 YJV32
Price :
0.1-5
Halogen Free :
Available
Conductor Material :
copper or Al-alloy
Description
26kV-330kV High Voltage XLPE Electrical Power Cables
Product Overview

High voltage XLPE insulated power cables designed for transmission and distribution of electrical energy in urban underground power grids, power station outgoing lines, industrial power supply, and underwater transmission applications.

26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
Technical Specifications
Parameter Specification
Conductor Material Copper or Aluminum
Insulation Material PVC or XLPE
Jacket Material PVC
Rated Voltage 26kV, 35kV, 66kV, 69kV, 110kV, 132kV, 220kV, 275kV, 330kV
Model Numbers YJV, YJLV, VV, VLV, VV22, VV32, YJV22
Standards BS, IEC, GB, ISO9001-2008, ISO14001-2004
Application Construction, underground power distribution
Construction Details
  • Conductor: Plain annealed stranded compacted circular copper or aluminium conductor to IEC 60228 class 2
  • Screen: Extruded semi-conductive compound
  • Metallic Screen: Copper tape or concentric layer of copper wires
  • Inner Sheath: Extruded layer of PVC ST2 or PE, LSZH
  • Outer Sheath: PVC type ST2 to IEC 60502 or PE, LSZH
  • Armoured Options: Steel tape armored, steel wire armored, Double galvanized steel tape/wire
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
Product Variants

Number of Cores: Single core, 2 cores, 3 cores, 4 cores, 5 cores, 3+1 cores, 3+2 cores, 4+1 cores

Common Sizes: 1mm² to 300mm² (1, 1.5, 2.5, 4, 6, 10, 16, 25, 35, 50, 70, 95, 120, 150, 185, 240, 300mm²)

Types Available: Ordinary type, flame-retardant type, fire-resistant type, low-smoke halogen-free type

Installation Guidelines
  • Minimum bending radius when laying cable should not be less than 10 times the outer diameter of the cable
  • YJV/YJLV cables are suitable for indoor, channel, and pipe laying, and can be buried in loose soil (cannot bear external forces)
  • YJV22/YJLV22 cables are designed for underground laying and can withstand external mechanical forces (but not large tensile forces)
  • Use specialized tools for cable laying (pay-off racks, guide rollers) to prevent mechanical damage
  • Keep cables away from heat sources during installation
  • When laying through pipes, inner diameter should not be less than 1.5 times the cable outer diameter
  • Do not squeeze cables when passing through pipes
  • Cable area should not exceed 40% of total pipe area
26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
Cable Types Available

PVC Insulated PVC/PE Sheathed Power Cables: Available in single core, 2 core, 3 core, 4 core, 5 core, 3+1 core, 3+2 core, 4+1 core configurations

XLPE Insulated PVC/PE Sheathed Power Cables: Available in single core, 2 core, 3 core, 4 core, 5 core, 3+1 core, 3+2 core, 4+1 core configurations

26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission 26kv - 330KV High Voltage XLPE Power Cable For Electrical Power Transmission
