900BPH Automatic Cap Loader 5 Gallon Water Bottling Machine
900BPH Automatic Cap Loader 5 Gallon Water Bottling Machine
900BPH Automatic Cap Loader 5 Gallon Water Bottling Machine
900BPH Automatic Cap Loader 5 Gallon Water Bottling Machine
900BPH Automatic Cap Loader 5 Gallon Water Bottling Machine
900BPH Automatic Cap Loader 5 Gallon Water Bottling Machine
900BPH Automatic Cap Loader 5 Gallon Water Bottling Machine
900BPH Automatic Cap Loader 5 Gallon Water Bottling Machine
Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
QGF-900
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
16000-25000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5sets per month
Delivery Time :
20-25 working days
Packaging Details :
Sea shipping Wooden case
Application :
5 gallon Bottle packing line
Capavity :
900 bottles per hour(for 18.9L bottle)
Barrel size :
270*490mm
Gas pressure :
0.6Mpa
Automatic De-capper :
Provided
Rotary external washer :
Provided
Automatic cap lifter-washer :
Provided
Automatic stacker :
Provided
Description

Description of 900BPH automatic cap loader 5 gallon water bottling machine

900BPH 3-5 gallon bottle filling machine main technical parameters:
Production capacity 900 barrels / hour
The filling capacity is 18.9l
Suitable for bottle type φ 270 * 490
Rated voltage 380V / 50Hz
Power 9.75kw
Total weight 3500kg


Filling machine, capping machine, main configuration:
1. Frame: 304 stainless steel.
2. Funnel, filling nozzle and materials in contact with liquid parts:316L stainless steel, piston POM
3. Pneumatic components: Italian brand penulead
4. PLC: Siemens, Germany
5. Touch screen: Siemens 7 "color touch screen
6. Photoelectric sensor: sick, Leeds, Germany
7. Relays and air switches: Schneider
8. Hopper pump: stainless steel screw pump
9. Motor drive: Schneider
10. Conveyor belt material: 82mm wide film belt POM chain.
11. Filling and capping conveying motor: domestic brand AC motor
12. Capping motor: 550W domestic brand AC motor
13. Filling motor: Panasonic servo motor
14. Filling machine sealing materials: PTFE, silicone
15. Filling machine shell: stainless steel, plexiglass.
16. Exposed parts: stainless steel, anodized aluminum plating, through electroplating 45 steel, plastic parts.

Equipment list of 900BPH 5 gallon bottle packing libe:

Items Name of machine Model Size(mm) Qty.
900BPH 5 gallon water packing line
1.1 Automatic De-capper BG-2 900*600*2000 1set
1.2 Rotary external washer RXT-3 1800*1550*1750 1set
1.3 Monoblock gallon rinser-filler-capper QGF-900 5200*2300*2200 1set
1.4 Heat Shrinking Machine / 800*600*1200 1set
1.5 Checking Light CL-1 1000*100*450 1pc
1.6 Conveyor Belt with Motor / 9m+2 motors 1suit
1.7 Ink jet code printer OH-338 347*220*100 1set
Option
1.8 Automatic cap lifter-washer SG-1 800*800*3000 1set
1.9 Automatic stacker 4*4*3 2400*1700*2000 1set
