Gear Reducer Gearbox For Heavy Duty Mining Equipment Offering Torque Transmission High Transmission Efficiency
Gear Reducer Gearbox For Heavy Duty Mining Equipment Offering Torque Transmission High Transmission Efficiency
Gear Reducer Gearbox For Heavy Duty Mining Equipment Offering Torque Transmission High Transmission Efficiency
Gear Reducer Gearbox For Heavy Duty Mining Equipment Offering Torque Transmission High Transmission Efficiency
Specifications
Brand Name :
ZTIC
Model Number :
Gear Reducer Gearbox
Certification :
ISO/CE
Place of Origin :
Henan, China
MOQ :
>=1 Sets
Price :
$500.00
Supply Ability :
1000.0 Set/Sets per Year
Packaging Details :
Standard packing or according to customer's requirement
Name :
Gear Reducer Gearbox
Suitable Industries :
Manufacturing Plant, Energy & Mining
Customization :
Acceptable
Power Kw :
630-1600
Gear Ratio :
4.3-273
Efficiency :
Up to 95%
Inputspeed :
Up to 1500 RPM
Heat Treatment :
Gear Grinding
Quality :
Super
Warranty :
1 Year
Description

Gear Reducer Gearbox For Heavy Duty Mining Equipment Offering Torque Transmission High Transmission Efficiency

1. Gear Reducer Gearbox Product Introduction

In mining operations such as excavation, crushing, screening and conveying, gearboxes are the core power transmission components that reduce speed and increase torque. As the "power heart" of mining machinery, they efficiently convert motor power into stable mechanical torque, ensuring reliable and continuous operation under heavy loads and harsh conditions.

2. Gear Reducer Gearbox Product Range

We provide a full range of heavy-duty gearboxes specially designed for mining equipment, including hard-tooth surface helical gearboxes, bevel helical gearboxes, planetary gearboxes, conveyor gearboxes, crusher gearboxes, elevator gearboxes and other custom models. Complete specifications and various structures can meet diverse transmission requirements.

3. Gear Reducer Gearbox parameters

Gearbox Type Adapted Mining Equipment Power Range (kW) Core Application Scenarios
Hardened Helical Gearbox Conveyors, Feeders, Winches 37–315 Heavy-duty continuous transmission, high dust concentration environments
Bevel Gearbox Screens, Small Crushers 45–220 Direction-changing transmission, medium impact working conditions
Planetary Gearbox Hoists, Ball Mills 200–800 High torque requirements, compact installation space
Conveyor-Specific Gearbox Belt Conveyors, Scraper Conveyors 75–160 Long-distance material transportation, continuous load operation
Crusher-Specific Gearbox Crushers, Sand Making Machines 110–500 High impact force, heavy-duty crushing operations
Hoist-Specific Gearbox Mining Hoists, Winches 160–630 Vertical/inclined material lifting, high reliability requirements
Customized Gearbox Special Mining Machinery (Custom-Adapted) 37–1000 Personalized transmission needs, harsh working condition customization

4. Gear Reducer Gearbox Inquiry & Purchase

With reliable quality and cost-effective performance, our gearboxes are deeply trusted by mining enterprises and equipment manufacturers. If you need high-quality mining gearboxes or customized solutions, please contact us for quotation and parameters. We sincerely welcome your inquiry and look forward to long-term cooperation with you!

Gear Reducer Gearbox For Heavy Duty Mining Equipment Offering Torque Transmission High Transmission EfficiencyGear Reducer Gearbox For Heavy Duty Mining Equipment Offering Torque Transmission High Transmission Efficiency

After-sales service

LUOYANG ZHONGTAI INDUSTRIES able to provide:

1. ENGINEERED SPARES - DESIGN AND MANUFACTURING

2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES

3. HUGE MACHINE SHOP CAPABILITIES

4. TRAINING PROGRAMMES

5. PREVENTATIVE MAINTENANCE PROGRAMS

6. PREVETATIVE MAINTENANCE SERVICES

7. COMPREHENSIVE MAINTENANCE PROGRAMS

LUOYANG ZHONGTAI INDUSTRIES’s Field Service Engineers are trained specifically in the LUOYANG ZHONGTAI INDUSTRIES brand group products but are capable of undertaking the servicing of other OEM brands. Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time.
