Specifications
Supply Ability :
5000 Set/Sets per Year
Feed Capacity :
500-2000L
Model Number :
Cement Plant Equipments
Application :
Mining supporting projects,Field construction without power supply
MOQ :
1 set/sets
Name :
MP Series Vertical Shaft Concrete Mixer
Hoist Power for Feeding Hopper :
4-22kw
Payment Terms :
L/C, T/T
Discharge Capacity :
750-3000L
Hydraulic Unloading Power :
2.2-4kw
Price :
negotiate
ischarge Weight :
1200-4800kg
Rated Mixing Power :
18.5-75kw
Certification :
IOS/CE
Place of Origin :
Henan, China
Model :
MP500-2000
Brand Name :
ZTIC
Classification :
Cement Plant Equipments
Description

Factory Direct Supply MP Vertical Shaft Concrete Mixer Cement Plant Equipments

1. MP Vertical Shaft Concrete Mixer Application Scope|Cement Plant Equipments
As a highly versatile concrete mixer, the MP vertical shaft model is suitable for a wide range of materials and operational environments. It handles standard commercial concrete with ease while also being capable of mixing specialized types, such as dry-hard concrete. These mixers are widely used in cement product plants, commercial concrete batching plants, road and bridge infrastructure sites, precast component factories, permeable brick production lines, and mine backfill mixing systems. They deliver stable performance across diverse scenarios—from temporary on-site mixing for construction projects to mass prefabrication in factories and underground backfill material mixing in mining operations.

2. MP Vertical Shaft Concrete Mixer Standard Technical Parameters|Cement Plant Equipments

Parameter Item

MP500

MP750

MP1000

MP1500

MP2000

Feed Capacity

500L

750L

1000L

1500L

2000L

Discharge Capacity

750L

1125L

1500L

2250L

3000L

Discharge Weight

1200kg

1800kg

2400kg

3600kg

4800kg

Rated Mixing Power

18.5kw

30kw

37kw

55kw

75kw

Hydraulic Unloading Power

2.2kw

2.2kw

3kw

3kw

4kw

Hoist Power for Feeding Hopper

4kw

7.5kw

11kw

15kw

22kw

Machine Size

2230*2080*1880mm

2580*2340*2195mm

2890*2602*2220mm

3230*2909*2470mm

3625*3230*2630mm

Machine Weight

2400kg

3900kg

6200kg

7700kg

9500kg


After-sales service
LUOYANG ZHONGTAI INDUSTRIES able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS

LUOYANG ZHONGTAI INDUSTRIES’s Field Service Engineers are trained specifically in the LUOYANG ZHONGTAI INDUSTRIES brand group products but are capable of undertaking the servicing of other OEM brands. Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time. LUOYANG ZHONGTAI INDUSTRIES also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.
