Specifications
Supply Ability :
5000 Set/Sets per Year
Feed Capacity :
1500L
Model Number :
Cement Plant Equipments
Application :
Mining supporting projects,Field construction without power supply
Rated Mixing Power :
55kw
MOQ :
1 set/sets
Name :
MP Series Vertical Shaft Concrete Mixer
Hoist Power for Feeding Hopper :
15kw
Payment Terms :
L/C, T/T
Discharge Capacity :
2250L
Hydraulic Unloading Power :
3kw
Price :
negotiate
ischarge Weight :
3600kg
Certification :
IOS/CE
Place of Origin :
Henan, China
Model :
MP1500
Brand Name :
ZTIC
Classification :
Cement Plant Equipments
Description

Reliable MP Vertical Shaft Concrete Mixer For Cement Plant Production Equipments

1. MP Vertical Shaft Concrete Mixer Product Introduction|Cement Plant Equipments
As core supporting Cement Plant Equipments for cement plants, the MP vertical shaft concrete mixer differs fundamentally from traditional horizontal shaft mixers. Its mixing shaft adopts a vertical layout, with feeding mechanism, heavy-duty mixing main unit and hydraulic unloading structure integrated into one compact and sturdy body. The vertical mixing structure eliminates blind mixing zones existing in horizontal shaft mixers, enabling materials to tumble and mix fully inside the mixing drum for superior mixing uniformity. It is a preferred mixing device for commercial concrete batching plants, cement product factories and mine filling mixing workshops. Featuring stable operation, it supports long-duration continuous mixing in factories and is widely matched with various cement building material production lines.

2. MP Vertical Shaft Concrete Mixer Standard Technical Parameters|Cement Plant Equipments

Parameter Item

MP500

MP750

MP1000

MP1500

MP2000

Feed Capacity

500L

750L

1000L

1500L

2000L

Discharge Capacity

750L

1125L

1500L

2250L

3000L

Discharge Weight

1200kg

1800kg

2400kg

3600kg

4800kg

Rated Mixing Power

18.5kw

30kw

37kw

55kw

75kw

Hydraulic Unloading Power

2.2kw

2.2kw

3kw

3kw

4kw

Hoist Power for Feeding Hopper

4kw

7.5kw

11kw

15kw

22kw

Machine Size

2230*2080*1880mm

2580*2340*2195mm

2890*2602*2220mm

3230*2909*2470mm

3625*3230*2630mm

Machine Weight

2400kg

3900kg

6200kg

7700kg

9500kg


3. ​MP Vertical Shaft Concrete Mixer Inquiry & Purchase Invitation|Cement Plant Equipments
The high-performance MP vertical shaft concrete mixer helps building material and mining enterprises reduce costs and increase production efficiency. With extensive experience in mining machinery and complete cement equipment sales, we maintain ample stock of the MP series mixers and offer customization options for equipment structure and fully automated loading production lines. Whether for sporadic project procurement, batch equipment upgrades for factories, or integration into mine backfill mixing systems, please feel free to contact us for a quote. We provide comprehensive, one-stop services—including tailored solutions for specific operating conditions, competitive factory-direct pricing, on-site installation and commissioning guidance, and full-lifecycle after-sales support. We welcome inquiries and partnership discussions from building material manufacturers, engineering contractors, and mining enterprises.
