OEM High Manganese Steel ball mill parts grinding steel balls
OEM High Manganese Steel ball mill parts grinding steel balls
OEM High Manganese Steel ball mill parts grinding steel balls
OEM High Manganese Steel ball mill parts grinding steel balls
OEM High Manganese Steel ball mill parts grinding steel balls
OEM High Manganese Steel ball mill parts grinding steel balls
Specifications
Place of Origin :
Henan, China
Brand Name :
CITIC ZT
Model Number :
Grinding Media GENERAL DESCRIPTION CITICIC has the capacity to delive
Certification :
ISO
Supply Ability :
100000 Ton/Tons per Year
Packaging Details :
Simple Package for ball mill grinding media
MOQ :
10 Set/Sets
Price :
$750.00 - $1,250.00 / Set
Condition :
New
Type :
Other
Capacity(t/h) :
Grinding Media
Dimension(L*W*H) :
Grinding Media
Grinding Media :
mill grinding balls
Material :
Steel
Series :
HH Series S Series T Series
Name :
ball mill grinding media
Product name :
ball mill grinding media
Application :
ball mill
Spare parts supplying :
Lifelong Provide
After sale service :
Life Time
The Machines classification :
Granding Mill Machine
Color :
Customerized
After-sales Service Provided :
Engineers available to service machinery overseas
Warranty :
12 Months
Port :
QingDao,ShangHai,TianJin
Description
Our Company

OEM High Manganese Steel ball mill parts grinding steel balls

ball mill grinding media Specifications

CITICIC has the capacity to deliver premium quality forged grinding balls of all sizes ranging from 22 mm to 165 mm

Product Description

ball mill grinding media

CITICIC has the capacity to deliver premium quality forged grinding balls of all sizes ranging from 22 mm to 165 mm (7/8” to 6½” aprox.) and in two grinding balls product lines: LK SAG, for SAG mills, and LK Grind, for ball mills.

Why choose CITICIC Grinding Media :

• Quality Management System certified ISO 9001:2008.
• We use the highest quality bar stock available, made with "clean steel" technology.
• Rigidly managed forging process ensuring spherical ball shape.
• High end heat treatment technology, based on CITICIC Elecmetal’s years of metallurgical experience guaranteeing long wear life
• Logistics is a key part of CITICIC Elecmetal grinding media offer: We currently have 8 distribution centers close to our customer base and are in process of adding more.

1 SAG Mill grinding balls

GENERAL DESCRIPTION

CITICIC provides grinding balls 100 - 165 mm (4" - 6.5" aprox.), specially designed for SAG mills.

CHEMISTRY

Limits C Mn P
(max.)		 S
(max.)		 Si Ni
(resid.)		 Cr Mo Cu
(resid.)		 Al
Upper Limit 0.90 1.02 0.022 0.022 0.40 0.10 1.05 0.15 0.15 0.05
Lower Limit 0.70 0.80 - - 0.20 0.70 0.03 - 0.02

HARDNESS (HRC)

Series Surface
(min. - max.)		 Volumetric
(min. - max.)		 Center
(min.)		 Applications
HH Series 61 64 58 62 50 Mills with minimal ball to liner impact
S Series 58 62 56 60 50 Normal milling operation
T Series 56 60 55 60 50 Mills with higher chance of ball to liner impact

HRC: Hardness Rockwell

HH: High Hardness

S: Standard

T: Tough

2 Ball mills grinding balls

GENERAL DESCRIPTION

CITICIC provides grinding balls 22 - 100 mm (0.88" - 4" aprox.), specially designed for ball mills.

CHEMISTRY

Limits C Mn P
(max.)		 S
(max.)		 Si Ni
(resid.)		 Cr Mo
(resid.)		 Cu
(resid.)		 Al
Upper Limit 1.00 1.00 0.025 0.025 0.30 0.10 0.50 0.01 0.15 0.05
Lower Limit 0.80 0.80 - - 0.20 - 0.40 - - 0.02

HARDNESS (HRC)

Series Surface
(min. - max.)		 Volumetric
(min. - max.)		 Center
(min.)		 Applications
ME Ultra Grind® 60 64 60 64 60 Ball mills

HRC: Hardness Rockwell

Grinding Ball Apps

GENERAL DESCRIPTION

This media guide is being provided by CITICIC to help you make the most effective use of grinding media in your mills. It includes the following sections.

SAG mills ball mill grinding media
Determination of your SAG mill’s power draw characteristics.
SAG Mill Steel Charge Estimation tool provides an estimate of the percent steel in the charge of your SAG mill based on the power draw and the total charge volume.
Ball impact energy chart to determine the impact energy of balls as a function of mill diameters.
Glossary of the terminology and symbols used in this section.

Ball mills ball mill grinding media
Determination of the recommended size of grinding ball to add to your mill.
Determination of your mill power draw characteristics, which are closely tied to the nature of the ball charge present in the mill.
Determination of various characteristics of the ball charge in your mill which are important in terms of its grinding and wear performance.
A glossary of the terminology and symbols used in this section.

Rod mills ball mill grinding media

Determination of the recommended rod size to add to your mill.
Determination of your mill power draw characteristics.
A glossary of the terminology and symbols used in this section.

OEM High Manganese Steel ball mill parts grinding steel ballsOEM High Manganese Steel ball mill parts grinding steel ballsOEM High Manganese Steel ball mill parts grinding steel balls

Our Factory

OEM High Manganese Steel ball mill parts grinding steel balls

Process Capability

OEM High Manganese Steel ball mill parts grinding steel balls

Foreigner Visit

OEM High Manganese Steel ball mill parts grinding steel balls

Packing

OEM High Manganese Steel ball mill parts grinding steel balls

Certifications

OEM High Manganese Steel ball mill parts grinding steel balls

FAQ

Q: Why we believe in luoyang zhongtai industries co., ltd:

A: 1. More than 30 years experience.

2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts.

3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.

Q:Delivery time:

A: parts lead time 1-2months, machines 2-3months.

Q:Payment terms:

A: Accept payment type: T/T, L/C, Western union,Cash.

30% deposit when signed contract. Full payment paid before shipping.

Q: Quality warranty?

A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.

Q: After sales service?

A: we can supply technical guide for machines running test and parts maintenance if end user needs.

Aftersales service
ZTIC Heavy Industries is your business partner in the After Market.
ZTIC able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS
