Steel Steam Chemical 400TPD Calcination Rotary Kiln
Steel Steam Chemical 400TPD Calcination Rotary Kiln
Steel Steam Chemical 400TPD Calcination Rotary Kiln
Steel Steam Chemical 400TPD Calcination Rotary Kiln
Steel Steam Chemical 400TPD Calcination Rotary Kiln
Steel Steam Chemical 400TPD Calcination Rotary Kiln
Steel Steam Chemical 400TPD Calcination Rotary Kiln
Steel Steam Chemical 400TPD Calcination Rotary Kiln
Steel Steam Chemical 400TPD Calcination Rotary Kiln
Steel Steam Chemical 400TPD Calcination Rotary Kiln
Specifications
Brand Name :
ZTIC
Model Number :
Cusotmized
Certification :
ISO/CE
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100 sets per year
Delivery Time :
30 workday
Packaging Details :
simple package
Type :
Rotary Drying Equipment
Product name :
Steam Calcination Kiln
Material :
steel
Keywords :
Rotary kiln
Color :
Customizable
size :
Customizable
Warranty :
1 Year
Description

Customizable high productivity steel Steam Calcination Kiln first-class chemical kiln

Possessing the domestic first-class chemical kiln R&D team, perfect inspection means and large precise manufacturing equipments and technology, CIC HMC has formed the perfect technology and production system of chemical kiln designing, manufacturing, installing and commissioning services.

Steel Steam Chemical 400TPD Calcination Rotary Kiln

Steam Calcination Kiln for Sodium Bicarbonate with Inner Recycling of Soda

Soda is an important fimdamental chemical product．The sodium bicarbonate’s calcination is one of the most important processesin soda production．in which the streanl calcinations kiIn is a key equipmem．

ZTIC Steam Calcination rotary kiln technical characteristics:
●　Kiln body is made of high quality composed of carbon steel or alloy steel plate and automatic welding;
●　Tyre,Support Roller,Open gear adopts alloy cast steel；
●　Sliding bearing with large gap not scraping tile bearing;
●　Transmission device adopts hard tooth surface reducer, flexible diaphragm coupling, dc motor;
●　Adopts hydraulic gear wheel;
●　Preheater scales were used respectively to veiw of kiln head, and cylinder pressure tight seal;
●　A slow drive device.

Steel Steam Chemical 400TPD Calcination Rotary Kiln

Technical Data:

Unit Product specifications and parameter values
Φ2.5*27(m) Φ2.8*27(m) Φ3*30(m) Φ3.2*32(m)
Diameter mm Φ2500 Φ2800 Φ3000 Φ3200
Length mm 27000 27000 30000 32000
main motor power kw 160 160 220 310
kiln Body main speed r/min 7 6.32 5.9 5.47
Slow speed 0.4 0.3 0.25 0.26
steam passes Design pressure Mpa 3.53 3.53 3.53 3.53
Design temperature C° 270 270 270 270
Operating pressure MPa 3.2 3.2 3.2 3.2
Operating temperature C° 219 219 243 260
Case length Working pressure Mpa normal pressures
Working temperature C° 238 238 238 238
Heat transfer area m2 >2500 >3100 >3600 >4000
Capacity t/d 400 520 660 800
Installation Angle % 2 2) 2 2
Weight kg 198000 228000 300800 350000
Maximumfeed weight kg 250000 270000 350000

Steel Steam Chemical 400TPD Calcination Rotary Kiln
