Specifications
MOQ :
100 Pieces Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union，L/C
Supply Ability :
10000 pieces per month
Delivery Time :
15 work days
Packaging Details :
BOX
Product Name :
Military Ballistic Armor
Material :
UHMWPE(HA930)
Size :
10"(25cm)x12"(30cm)x0.59"(1.5cm)
Weight :
0.95kg (2.1 lbs)
Color :
Black
Angle cutting size :
2.17"(5.5cm)x3.54"(9cm)
Description

PE Bulletproof Insert Plate Military Ballistic Armor Three Levels Of Bulletproof Plate


Product description

Ballistic inserts are usually used in conjunction with a bulletproof vest or tactical vest. The front plate protects the front and back of the body, while the side plate protects the sides of the body. The side panels provide protection to the sides of the body. The cut corners are normal for the front of the body and square for the back. The types of materials used to make bulletproof inserts can be roughly divided into 4 types: bulletproof steel, PE polyethylene, PE + aluminium oxide and PE + silicon carbide. All types of material models are available.
Now the more widely used to occupy the mainstream is the ceramic bullet-proof insert plate. We will introduce the principle of ceramic inserts and the differences between them.
The principle is that when a bullet impacts a bulletproof insert, the bullet first impacts the top ceramic layer, which breaks up when it encounters a bullet with huge kinetic energy, and also transfers the huge impact energy from the impact point to the surrounding area to absorb the huge kinetic energy of the bullet. When the bullet passes through the ceramic layer, it has lost most of its kinetic energy. When the bullet reaches the polyethylene layer, the polyethylene consumes the bullet's kinetic energy by stretching and wraps around the bullet and the shrapnel, a process that has little effect on the human body and provides excellent protection.

Notes on use:

Weight tolerance +/- 50g, dimensional tolerance +/- 3mm ;

Use temperature should not exceed 70 ℃;

Do not drop during use;

Inspection is required at each insertion;

Inserts must be stored in a dry room with constant room temperature;

Wipe with a damp cloth;

Do not bend or change.


Specification

Product Name Military Ballistic Armor
Curvature Polybolic
External processing Polyurea
Protection level NIJ0101.06 Level III Associate Defense
Test bullets per plate 6 shots
Test Distance 15 m
Speed measurement points 3m from the muzzle
Protective bullets 7.62x51 M80 NATO;7.62x39 AK47 MSC
Bullet speed 847±9.1m/s; 730±9.1m/s
Depression requirements ≤44mm


Details Images

PE Bulletproof Military Ballistic Armor 12x10

PE Bulletproof Military Ballistic Armor 12x10
PE Bulletproof Military Ballistic Armor 12x10
PE Bulletproof Military Ballistic Armor 12x10

Company Profile

PE Bulletproof Military Ballistic Armor 12x10
1. Company year and main product type:
Established in 2021, Chengdu Bigan Trading Co., Ltd. is a supplier of high-quality outdoor clothing, outdoor equipment supplies and military quality civil products.
2. Export country of the company:
It is mainly aimed at the global outdoor products market and WG group.
3. Functions that can be brought to customers:
Provide excellent military quality outdoor supplies and equipment.
4. Company services:
What we offer:
1) Good quality control
2) Highly competitive prices
3) state-of-art technology products
4) Best professional team of lifestyle consumer electronics.
5) Smooth communication


About factory
PE Bulletproof Military Ballistic Armor 12x10
FAQ
A) How could I get a sample? Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order.
B) Sample time? Existing items: Within 15- 20 days.
C) Whether you could make our brand on your products? Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
D) Whether you could make your products by our color? Yes, The color of products can be customized if you can meet our MOQ.
E) How to guarantee the quality of your products? 1) Strict detection during production. 2) Strict sampling inspection on products before shipment and intact product packaging ensured.
