Specifications
Brand Name :
GOWELLDE
Model Number :
CUT60
Certification :
CE
Place of Origin :
GUANGDONG,CHINA
MOQ :
100 Pieces
Price :
US $250-280/ Piece
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30000PCS/MONTH
Delivery Time :
30 DAYS
Packaging Details :
CARTON
Brand :
Gowellde
Type :
CUT60
Warranty :
1 Year
Voltage :
220V/380V
Weight :
23
Dimension(l*w*h) :
435*211*334
Efficiency (%) :
80
Protection class :
IP21
No-load voltage (V) :
DC310V
Insulation class :
F
Description

CUTC60 Portable Plasma Cutter Function IP21 Air Pump IGBT Plasma Cutter,Cutting Machine

FEATURES
.Built in Air Pump IGBT Air Plasma Cuter,Cutting Machine with MMA Function
.Using advanced IGBT module technology and soft-switching technology
· Cutting capacity increases 1.8 times higher in cutting speed comparing with flame cutter.
· Advamced pilot arc system design,100% arc start,arc continuously

· Bulit-in over current,over heat,less voltage,lack of phase protections,more safety on operation.
· Suitable for cutting stainless steel, copper, iron and aluminum metal etc.
· Simple operation and smooth cutting surface.
· HF touched Arc-starting cutting

TECHNICAL PARAMETER
Item CUT60 CUT60S CUT60L
Input power source(±15% 50/60HZ) 1~AC380V 1~AC220V 1~AC380/220V
Rated Input current (A) 12.3 45 45/12.3
Rated input power capacity (KVA) 8.1 9.9 9.9/8.1
Output current range (A) 20-60 20-60 20-60
No-load voltage (V) DC310V DC310V DC310V
Cutting Thickness 1-20mm 1-20mm 1-20mm
Rated duty cycle (%) @40℃ 60 60 60
Efficiency (%) 80 80 80
Power factor (cosφ) 0.93 0.73 0.93
Protection class IP21 IP21 IP21
Insulation class F F F
Dimensions (mm) 435*211*334
Weight (Kg) 23 23 23

CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal

CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal

CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal

CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal

CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal

CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal

CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal

CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal

CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal
