Specifications
Brand Name :
TYHE
Model Number :
TJP37FG
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
37mm size
Voltage :
6-24V
Speed :
5-600rpm custom
Torque :
1.8N.m
Gear material :
Powder metallurgy, steel gears
Commutation :
brushed
Type :
Gear Motor, DC Spur Gear Motor
Usage :
Printer
Keywords :
Noiseless 8v 12v 24v 12 Volt High Power High Rpm 15w 50w 50rpm 40 Rpm 12kg Cm Rs555sh Micro Dc Gear Motor
Description

Products Description

Noiseless 8v 12v 24v 12 Volt High Power High Rpm 15w 50w 50rpm 40 Rpm 12kg Cm Rs555sh Micro Dc Gear Motor

2D drawing

Noiseless RS555 12V High Rpm DC Motor 12kg Cm 15W 50W 50rpm 40Rpm


Noiseless RS555 12V High Rpm DC Motor 12kg Cm 15W 50W 50rpm 40Rpm

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
RS555 6 6000 560 4800 1.92 14.20 7.14 61.85 42.60 13.00
RS555 12 3000 110 2400 0.42 12.30 3.09 62.07 36.90 3.00
RS555 24 5000 150 4000 0.49 17.50 7.33 62.12 52.50 3.20
RS555 24 6000 160 4800 0.53 16.80 8.44 66.18 50.40 3.50
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 6V-6000RPM Input 12V-3000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
25.5 81 8.2 585.4 5.78 94.32 282.95 292.7 2.50 81.70 245.09
25.5 73 11.7 410.3 5.21 121.28 363.85 205.1 2.26 105.05 315.16
25.5 73 14.7 326.5 5.21 152.38 457.14 163.3 2.26 131.99 395.97
25.5 73 19.1 251.3 5.21 197.99 593.97 125.7 2.26 171.50 514.50
27.5 65.6 27.2 176.5 4.68 253.37 760.12 88.2 2.03 219.47 658.41
27.5 65.6 34.4 139.5 4.68 320.44 961.33 69.8 2.03 277.57 832.70
27.5 65.6 44.5 107.9 4.68 414.53 1243.58 53.9 2.03 359.06 1077.18
29.5 59 63.5 75.6 4.21 532.00 1596.01 37.8 1.82 460.82 1382.46
29.5 59 80.3 59.8 4.21 672.75 2018.26 29.9 1.82 582.74 1748.21
29.5 59 104.0 46.2 4.21 871.31 2500.00 23.1 1.82 754.73 2264.18
32.5 53 148.0 32.4 3.78 1113.85 2500.00 16.2 1.64 964.81 2500.00
32.5 53 187.0 25.7 3.78 1407.36 2500.00 12.8 1.64 1219.05 2500.00
32.5 53 242.0 19.8 3.78 1821.29 2500.00 9.9 1.64 1577.60 2500.00
35.5 47.8 346.0 13.9 3.41 2348.51 2500.00 6.9 1.48 2034.27 2500.00
35.5 47.8 437.0 11.0 3.41 2500.00 2500.00 5.5 1.48 2500.00 2500.00
35.5 47.8 565.0 8.5 3.41 2500.00 2500.00 4.2 1.48 2500.00 2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-5000RPM Input 24V-6000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
25.5 81 8.2 487.8 5.94 116.24 348.71 585.4 6.84 111.59 334.76
25.5 73 11.7 341.9 5.35 149.47 448.40 410.3 6.16 143.49 430.47
25.5 73 14.7 272.1 5.35 187.79 563.38 326.5 6.16 180.28 540.84
25.5 73 19.1 209.4 5.35 244.00 732.01 251.3 6.16 234.24 702.73
27.5 65.6 27.2 147.1 4.81 312.26 936.77 176.5 5.54 299.77 899.30
27.5 65.6 34.4 116.3 4.81 394.91 1184.74 139.5 5.54 379.12 1137.35
27.5 65.6 44.5 89.9 4.81 510.86 1532.58 107.9 5.54 490.43 1471.28
29.5 59 63.5 63.0 4.32 655.64 1966.91 75.6 4.98 629.41 1888.24
29.5 59 80.3 49.8 4.32 829.10 2487.29 59.8 4.98 795.93 2387.80
29.5 59 104.0 38.5 4.32 1073.80 2500.00 46.2 4.98 1030.85 2500.00
32.5 53 148.0 27.0 3.88 1372.70 2500.00 32.4 4.48 1317.79 2500.00
32.5 53 187.0 21.4 3.88 1734.43 2500.00 25.7 4.48 1665.05 2500.00
32.5 53 242.0 16.5 3.88 2244.55 2500.00 19.8 4.48 2154.77 2500.00
35.5 47.8 346.0 11.6 3.50 2500.00 2500.00 13.9 4.04 2500.00 2500.00
35.5 47.8 437.0 9.2 3.50 2500.00 2500.00 11.0 4.04 2500.00 2500.00
35.5 47.8 565.0 7.1 3.50 2500.00 2500.00 8.5 4.04 2500.00 2500.00

Please let us know your requirements and we will provide you with transmission solutions.
