Specifications
Brand Name :
VIC-TECH
Model Number :
PM20S-020-515
Certification :
RoHS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1Unit
Price :
$2~$5/Unit
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
1000000 Units/year
Delivery Time :
15-30 work days
Packaging Details :
intertional carton box
Step Angle(degrees): :
18
Phase :
2
Voltage :
12V DC
Resistance :
150Ω/phase
Type :
Permanent Magnet
Step angle :
18°/step
Motor size :
20mm diameter
Description

20mm diameter 12V DC 18 degrees step angle bipolar 4 wires round shaft stepper motor


This 20mm diameter stepper motor Model No. PM20S-020-515, with 150 Ω/ phase coil resistance.

This resistance is designed for 12V DC voltage.

The coil resistance is based on required driving voltage.

If customer wants lower voltage, for example 5V DC, we are able to lower coil resistance to matcg 5V voltage.

Also, the motor’s other parameters, such as cable length, shaft length, connector type, flange cap design and so on, are all customizable.

We are able the adjust motor’s design and parameter based on customer’s needs.

On top of that, we are able to assemble gear/gearbox on the motor if you need to.

Please let us know your project requirement, and we will make assessment, and recommend a suitable design and parameter.

Mechanical Dimension: mm

20mm diameter 12V DC 18 degrees step angle bipolar stepper motor with customizable options and gearbox assembly

Technical Features

  • 15mm permanent magnet stepper motor, can be equipped with a gearbox

  • Compliance with EU Environment Standard

  • All parameters can be customized

Typical Applications

  • Intelligent Security Products

  • Camera Lenses

  • Door Locks

  • Wearable device

Specifications

Product Model No.

PM20S-020-515

Motor type

Stepper motor

Motor size

20mm diameter

Rated voltage

12V DC

Coil resistance

150Ω/phase

Step angle

18°/step

Holding torque

53gf*cm


Competitive Advantage

  • High quality and the best price.
  • Fast deliver,storage company and rich inventory
  • Near Shanghai port, the traffic is very convenient.


Type Of Wire Connect For Reference

Motor input method with Pin type, FPC, PCB, Lead wire etc.

These can be customized according to customer needs.

20mm diameter 12V DC 18 degrees step angle bipolar stepper motor with customizable options and gearbox assembly


Type of Fixture Cover

The regular models are shown in the figure, and the special sizes can be customized.

20mm diameter 12V DC 18 degrees step angle bipolar stepper motor with customizable options and gearbox assembly

Product Detail Presentation

20mm diameter 12V DC 18 degrees step angle bipolar stepper motor with customizable options and gearbox assembly
