11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal
11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal
11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal
11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal
11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal
11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal
11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal
11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal
Specifications
Brand Name :
SECORE
Model Number :
BLS-4614O
Certification :
CE ROHS
Place of Origin :
China
MOQ :
100
Price :
Negotiated The Price
Payment Terms :
T/T, D/A
Supply Ability :
100000pcs per month
Delivery Time :
10-12 working days
Packaging Details :
50pcs per carton or as request
No-load speed :
1000RPM
Rated Speed :
880rpm
Rated voltage :
11.1V or per request
Rated current :
0.36A
Rated torque :
320g.cm
Motor size :
46mm*14mm
Product name :
11.1V round 46mm brushless dc motor
Typical usage :
Three axis gimbal, stabilizer, ptz cam
Noise :
< 45dB
Protection :
Over-heat, Over-current
Bearing :
Ball bearing
Controlling :
CW/CCW, PWM, Start/Cease, FG feedback
Description

Factory Direct Supply Brushless Dc Motor 11.1V Low Noise Round 46mm Ec Motor For 3-Axis Gimbal

Specification of 4614 Brushless DC out runner Motors :

•Model #: BLS-4614O
•Voltage: 11.1V or as per request
• Bearing: Ball bearing

• Speed: 800-1200 RPM

•Low Noise, long life, high durability

MODEL VOLTAGE NO LOAD AT MAXIMUM EFFICIENCY STALL
SPEED
RPM		 CURRENT
A		 SPEED
RPM		 TORQUE
gf.cm		 CURRENT
A		 TORQUE
gf.cm		 CURRENT
A
BLS-4614O 11.1 1040 0.09 880 320 0.36 2080 1.8


Performance curve:

11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal


Dimension:

11.1V Brushless Dc Motor Round 46mm Ec 0.36A For 3 Axis Gimbal
