Standing-floor Phone Glass Optical Measurement Machine MPC500
Standing-floor Phone Glass Optical Measurement Machine MPC500
Specifications
MOQ :
1 Piece
Supply Ability :
50, 000PCS/Year
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Place of Origin :
CHINA
Price :
negotiation
Brand Name :
MICRO ACCURACY
Model Number :
MPC500
Certification :
CE, ISO
Delivery Time :
10 WORKING DAYS
Packaging Details :
Vacuum Free Fumigation Plywood Export Package
Model :
MPC500
Name :
Vision Measuring Microscope
Travel Xy Axis :
500*400mm
Travel Z Axis :
200mm
Z Axis Working Range :
105mm
Feed Mechanism :
Manual
Resolution :
1 micron
Accuracy :
(2.5+L/150)µm, L=measuring length(mm)
Repeatability :
0.003mm
HS Code :
9031809090
Description

Phone Glass Optical Measurement Machine

Usage

MPC series video measuring machine is suitable for all application fields with the purpose of two-dimensional coordinate measurement. It is widely used in precision machinery, electronics, instrumentation, plastics, mobile phone tablet, hardware mold, PCB, LCD, LED display and other industries.


Features & Advantages

■ High-precision marble base, table and column to ensure high stability and rigidity

■ Marble table design, with precision V-shaped cross rail, ensure long-term use without deform, effectively guarantee high mechanical precision

■ High-quality optical system and high-resolution CCD ensure sharp image edges

■ Three-ring and eight-zone LED ring surface cold light source and contour light source, avoid the deformation of precision parts caused by the heat from light

■ Optional fully automatic zoom lens, no need re-calibrate when changing magnification, save calibration time and avoid human error

■ Optional Renishaw contact probe for height, depth and other 3D measurement

■ Independent research and development of image measuring software, powerful and easy to operate

Technical data

Model MPC500
X,Y axis travel(mm) 500*400
Stage glass size(mm) 657*557
Z axis travel(mm) 200
X,Y,Z axis resolution (μm) 1
Length unit Linear scale
Measuring accuracy (μm) 2.5+L/150 L=measuring length (mm)
Operation method Manual
Camera High resolution CCD camera
Detent zoom lens 0.7X~4.5X
Video magnification 27X~190X
Object of view 10.6mm~1.6mm
Working distance 90mm
Measuring software LeaderView 2D measuring software
Illumination Transmitted LED ring light
Contour LED light
Power supply AC100~240V 50/60Hz
