High-Precision Programmable Power Source for Energy Meter Calibration
High-Precision Programmable Power Source for Energy Meter Calibration
Specifications
Brand Name :
GENY
Model Number :
YCS-103
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Negotiation
Payment Terms :
L/C,T/T,D/P
Supply Ability :
100/Year
Delivery Time :
30 days after order confirmed
Packaging Details :
Plywood case
Harmonics :
2nd – 21st free programmable
Distortion factor :
< 0.3% for linear resistance load
Voltage Supply :
3×220/380V±10% or customized 50/60Hz±2Hz
Test voltage output (Phase-Neutral) :
3×(24V – 288V) or customized
Description
High-Precision Programmable Power Source for Energy Meter Calibration
Advanced programmable power source designed specifically for precision energy meter calibration with exceptional accuracy and stability.
Key Features
  • High-accuracy output with exceptional stability
  • RS232 interface for automated operation
  • Optional keyboard support for convenient manual operation
  • Programmable 2nd-21st harmonic output with amplitude and phase angle settings
  • Durable aluminum alloy construction - lightweight, robust, and corrosion-resistant
  • Integrated protection against overload, short-circuit voltage, and open-circuit current conditions
  • User-friendly control software for simple and efficient operation
Primary Applications
  • National utility companies
  • Government metrology and calibration authorities
  • Large-scale energy meter manufacturers
Competitive Advantages
  • Premium-quality design and manufacturing
  • High power capacity:
    • Maximum voltage power: 1000 VA
    • Maximum current power: 1500 VA
  • Outstanding power output stability
  • Ultra-low distortion factor (<0.3%) under linear resistive load conditions
Technical Specifications
Model YCS-103-250 YCS-103-600 YCS-103-1200 YCS-103-2500
Voltage Specifications
Test voltage output (Phase-Neutral) 3×(24V - 288V) or customized
Power of the voltage output 3×100VA 3×250VA 3×500VA 3×1000VA
Resolution Better than 0.01% of full scale value of range
Setting accuracy Better than 0.05% at the final range value
Stability Better than 0.005%/h (integration time 150 s)
Load regulation from 0-max. load < 0.01%
Distortion factor < 0.3% for linear resistance load
Harmonics 2nd - 21st free programmable
Current Specifications
Test current output 3×(1mA - 100A)
Power of the current output 3×150VA 3×350VA 3×750VA 3×1500VA
Resolution Better than 0.01% of full scale value of range
Setting accuracy Better than 0.05% at the final range value
Stability Better than 0.005%/h (integration time 150 s)
Load regulation from 0-max. load < 0.01%
Distortion factor < 0.3% for linear resistance load
Harmonics 2nd - 21st free programmable
Additional Parameters
Phase angle range 0 - 360°
Phase angle resolution 0.01°
Phase angle setting accuracy 0.1°
Frequency range 45Hz - 65Hz
Frequency resolution 0.01Hz
Voltage supply 3×220/380V±10% or customized 50/60Hz±2Hz
Ambient temperature -10°C - +40°C
Relative humidity 35% - 85%
