High-Precision Energy Meter Test Bench for Electricity Meter Calibration
High-Precision Energy Meter Test Bench for Electricity Meter Calibration
Specifications
Brand Name :
GENY
Model Number :
YC1893-24
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
negotiation
Payment Terms :
L/C,T/T,D/P
Supply Ability :
30 PCS per month
Delivery Time :
30 days after order confirmed
Packaging Details :
Plywood case
Customized :
Customized
Theory :
Electronic Meter
Test voltage output(Phase-Neutral) :
3x(24V~288V)(or customized)
Power of the current output :
Max. 3x750VA
Description

High-Precision Energy Meter Test Bench for Electricity Meter Calibration


Guangzhou GENY Electric Co., Ltd. is a leading energy meter test bench manufacturer with more than 30 years of industry experience. As the first company in China to export energy meter test benches, GENY has supplied high-precision testing equipment to customers in over 37 countries worldwide.


Our test bench is designed and manufactured in strict compliance with IEC 60736, ensuring exceptional accuracy, reliability, and long-term performance. It supports a wide range of electricity meter calibration requirements for both current applications and future testing standards.


Additionally, Guangzhou GENY Electric Co., Ltd. offers professional OEM and ODM services, allowing customers to customize energy meter test benches according to their specific technical needs, branding preferences, and application environments.


Specifications


Technical spec. YC1893D-24
Number of meter positions 24
Accuracy 0.05 / 0.02
Power Source YCS-103-1200
Standard Meter SZ03A-K6 / SZ03A-K8
Scanning Head YCG-S Series
Voltage
Test voltage output(Phase-Neutral) 3x(24V~288V)(or customized)
Power of the voltage output Max. 3x500VA
Resolution Better than 0.01% of full scale value of range
Setting accuracy Better than 0.05% at the final range value
Stability Better than 0.005% /h (integration time 150s)
Load regulation from 0~max. load Better than 0.01%
Distortion factor Better than 0.3% for linear resistance load
Harmonic 2nd~21st free programmable
Current
Test current output 3x(1mA~100A)
Power of the current output Max. 3x750VA
Resolution Better than 0.01% of full scale value of range
Setting accuracy Better than 0.05% at the final range value
Stability Better than 0.005% /h (integration time 150s)
Load regulation from 0~max. load Better than 0.01%
Distortion factor Better than 0.3% for linear resistance load
Harmonic 2nd~21st free programmable
Phase angle
Range 0~360⁰
Resolution 0.01⁰
Setting accuracy 0.1⁰
Frequency
Range 45Hz~65Hz
Resolution 0.01Hz
Error display
Type of error display Red LED
Resolution of error displays 8 digitals
Other
Voltage supply 3x220/380V±10%(or customized)
50/60Hz ±2Hz
Ambient temperature -10°C~+40°C
Relative humidity 35%~85%
