Industrial Grade Smart Meter Test System
Industrial Grade Smart Meter Test System
Specifications
Brand Name :
GENY
Model Number :
YC1893D
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Negotiation
Payment Terms :
L/C,T/T,D/P
Supply Ability :
100/Year
Delivery Time :
30 days after order confirmed
Packaging Details :
Plywood
Model NO. :
YC1891D
Power Supply :
AC220V±10%, 50Hz±2Hz
Output Voltage Range :
24V ... 288V
Output Current Power :
2000VA (Max)
Description

Industrial Grade Smart Meter Test System


Technical Specifications


Power Supply

  • Input Voltage: 240/415 V AC (+5% / -10%) or customizable

  • Frequency: 50/60 Hz ±2 Hz

  • Power Capacity: > 3 × 6 kVA

  • Ambient Temperature: -10°C to +40°C

  • Relative Humidity: 35% to 95% RH

  • System Grounding: Neutral solidly grounded

  • Surge Protection Level: ≥ 10 kV / 120 Joules (10/1000 µs)

Power Source

Voltage Output

  • Test Voltage (Phase–Neutral): 3 × (24 V – 500 V) or customizable

  • Output Power: 3 × 100 VA

  • Resolution: < 0.01% of full-scale value

  • Setting Accuracy: < 0.05% at final range value

  • Stability: < 0.005%/h (integration time: 150 s)

  • Load Regulation (0–max load): < 0.01%

  • Distortion Factor: < 0.3% for linear resistive load

  • Harmonics: 2nd to 21st, freely programmable

Current Output

  • Test Current: 3 × (1 mA – 120 A)

  • Output Power: 3 × 150 VA

  • Resolution: < 0.01% of full-scale value

  • Setting Accuracy: < 0.05% at final range value

  • Stability: < 0.005%/h (integration time: 150 s)

  • Load Regulation (0–max load): < 0.01%

  • Distortion Factor: < 0.3% for linear resistive load

  • Harmonics: 2nd to 21st, freely programmable

Phase Angle

  • Range: 0° – 360°

  • Resolution: 0.01°

  • Setting Accuracy: 0.1°

Frequency

  • Range: 45 Hz – 65 Hz

  • Resolution: 0.01 Hz

Reference Standard

Power Supply

  • Voltage: AC 220 V ±10%

  • Frequency: 50 Hz ±2 Hz

  • Max Power Consumption: 45 VA

Operating Conditions

  • Ambient Temperature: 10°C – 30°C

  • Relative Humidity: 45% – 75% RH

  • External Magnetic Field Intensity: ≤ 0.025 mT

  • Frequency Range: 45 Hz – 65 Hz

Industrial Grade Smart Meter Test System

Industrial Grade Smart Meter Test System

Industrial Grade Smart Meter Test System

Industrial Grade Smart Meter Test System
