High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
Specifications
Brand Name :
LaiDi
Model Number :
RW-05
Certification :
ISO9001
Place of Origin :
Hebei, China
MOQ :
10tons
Price :
US$700-US$800
Payment Terms :
T/T
Supply Ability :
10tons/day
Delivery Time :
7-10 work day
Packaging Details :
Wooded Pallet
Product Name :
Razor Barbed Wire
Material :
Low Carbon Steel
Surface Treatment :
Galvanized
Wire Diameter :
2.5mm
Surface Treament :
Hot Dipped Galvanized
Specification :
BTO-22 ,CBT-65, CBT-60
Specimen :
Free provide
Zinc Coated :
40-60g/mm2
Coating :
Zinc Coated / Galvanized
Rollweight :
10-15 kg
Wiregauge :
12.5-14 gauge
Feature :
Anti-corrosion
Key Words :
concertina coils barbed wire
Characteristics :
High Tensile Strength Wire
Description
High Tensile Stainless Steel Cross Razor Barbed Wire Coil 450mm Diameter
High-security razor barbed wire concertina coils designed for maximum perimeter protection in demanding applications.
Product Overview
Razor blade wire is available in two primary types: galvanized razor wire and PVC razor wire. This modern security fencing material is manufactured from hot-dipped galvanized steel sheets or stainless steel sheets, offering superior protection and fencing strength for high-security applications.
Common installation models include straight type razor wire, concertina coils, crossed type, and flat type configurations.
Available Models
BTO10, BTO11, BTO12, BTO22, BTO28, BTO30, CBT65, CBT60
Technical Specifications
  • Normal hot dipped galvanized razor wire (40-60g)
  • Heavily zinc coated razor wire (70-270g)
  • Stainless steel 304/316 grades razor wire
  • Clips of concertina wire: 3 clips, 5 clips or without clips
  • Coil Diameter options: 300mm, 450mm, 500mm, 600mm, 700mm, 800mm, 950mm, 1000mm
Detailed Specifications
Reference Model Thickness (mm) Wire Diameter (mm) Barb Length (mm) Barb Width (mm) Barb Spacing (mm)
BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 26±1
BTO-15 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 34±1
BTO-28 0.5±0.05 2.5±0.1 28 15 45±1
CBT-30 0.5±0.05 2.5±0.1 30 18 45±1
CBT-60 0.6±0.05 2.5±0.1 60±2 32±1 100±1
CBT-65 0.6±0.05 2.5±0.1 65±2 21±1 100±1
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
Product Highlights
  • Robust Protection: Razor barbed wire design prevents climbing and ensures safety
  • High-Durability Protection: Strong physical barrier for secure perimeter defense
  • Flexible Installation: Easy to set up and adapt to various environments
  • Psychological Deterrence: Effective in deterring unauthorized access and trespassing
  • Customizable Options: Multiple sizes for different applications and needs
Key Features & Benefits
Complete Perimeter Security Solution
  • Deterrent: Effective prevention of illegal intrusions
  • Durability: Long-lasting security with minimal maintenance
  • Coverage: Comprehensive protection for extended boundaries
  • Security: Strong deterrent force to eliminate safety hazards
Performance Advantages
  • Unbreakable Construction: High-strength steel with anti-corrosion treatment provides 8-9 year lifespan
  • Ultimate Deterrent: Sharp blade design creates effective psychological and physical barriers
  • Economically Efficient: High cost-effectiveness reduces overall perimeter security costs
Applications
Double twist barbed wire provides high-level security fencing fabricated with high-tensile wire. The design effectively deters and stops aggressive perimeter intruders with piercing razor blades that make climbing and touching extremely difficult.
Common Applications:
  • Prisons and detention facilities
  • Government buildings and national security installations
  • Residential properties and private building security
  • Cottage fencing and high-security perimeter applications
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
Packaging Options
  • Compression rolls: 5 rolls, 10 rolls, or more rolls as one bundle
  • Water-proof paper inside with woven bag outside
  • 1 roll, 3 rolls or 5 rolls in one carton
  • Custom packaging available as per customer request
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
Manufacturer Information
Anping LaiDi Wire Mesh Products Co., Ltd. is an integrated industry and trade enterprise located in Anping County, Hebei Province - China's wire mesh production base. The company operates advanced manufacturing machinery and maintains ISO9001:2000 international quality standards.
Specializations:
Gabion mesh, steel mesh, fence mesh, slope mesh, windproof mesh, hook mesh, plastic coated wire, and decorative mesh products.
Export Markets:
Europe, South America, Japan, South Korea, United States, Canada, Middle East, and Southeast Asia.
High Tensile Strength Hot Dipped Galvanized Razor Barbed Wire Concertina Coils 450mm Diameter
