Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Specifications
Brand Name :
LaiDi
Model Number :
G02
Certification :
ISO9001:2015
Place of Origin :
Hebei, China
MOQ :
50 pcs
Price :
US$4-US$200
Payment Terms :
T/T
Supply Ability :
500 pcs per day
Delivery Time :
15-20 days
Packaging Details :
in bulk
Product Name :
Galvanized steel grating
Material :
Carbon steel
Surface Treatment :
Hot dipped galvanized
Color :
Sliver
Type :
Plain bar
Certificate :
ISO9001
Application :
Office building
Warranty :
1 year
Grate Mesh :
30x100mm
Steel Thcikness :
3.0mm
Description
Q235 Heavy Duty Driveway Platform Walkway Floor With Steel Grating
Product Specifications
Attribute Value
Product Name Galvanized steel grating
Material Carbon steel
Place of Origin Hebei, China
Surface Treatment Hot dipped galvanized
Color Silver
Type Plain bar
Certificate ISO9001
Application Office building
Brand Name LaiDi
Warranty 1 year
Grate Mesh 30x100mm
Steel Thickness 3.0mm
Product Description

Q235 Metal Building Materials Rain Water Drainage Trench Driveway Galvanized Grating

Galvanized Steel Grating Description

Steel grating is also called steel frame lattice or steel grid plate. Steel bar grating with high strength and firm structure is made up of carbon steel, aluminum steel, or stainless steel. According to the manufacturing methods, it can be divided into four types: welded, press-locked, swage-locked, and riveted gratings. According to the surface shapes, it can be divided into smooth and serrated gratings. With various styles and sizes for choice, steel gratings are widely used in everyday life, such as stair treads, walkways, platforms, floors, various covers, wheeled equipment, security screens, heavy-duty constructions, industrial and so on.

Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Technical Specifications
Bearing bar 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10, 100x10mm etc;
I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc
US standard: 1'x3/16', 1 1/4'x3/16', 1 1/2'x3/16', 1'x1/4', 1 1/4'x1/4', 1 1/2'x1/4', 1'x1/8', 1 1/4'x1/8', 1 1/2'x1/8' etc.
Bearing bar pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Cross bar pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2' & 4' etc
Material Grate ASTM A36, A1011, A569, Q235, S275JR, SS304, Mild steel & Low carbon steel, etc
Surface treatment Black, self color, hot dip galvanized, painted, spray coating
Grating Type Plain / Smooth, Serrated /teeth, I bar, serrated I bar
Standard China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88), UK: BS4592-1987, Australia: AS1657-1985, Germany: DIN24537-1-2006, Japan: JIS
Key Features
  • Resistant to extremely high temperature
  • Corrosion resistance and alkaline resistance
  • Anti-rust
  • Skid resistance
  • Very rigid surface can stand heavy wear and tear
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Applications

Steel grating has been widely used in all walks of life worldwide. It is mainly used as platform plates, ditch covers, stair treads, and building ceilings. The products feature high strength, light structure, high load-bearing capacity, and convenience for loading. The hot-dipped zinc coating provides excellent anti-corrosion resistance.

Applications include:

  • Rotation ways, channels, and platforms for pump rooms and engine rooms in various ships
  • Flooring in various bridges such as railway bridge sidewalks, over-bridges across the street
  • Platforms for oil extraction sites, car washing sites, and air towers
  • Fencings for car-parks, buildings, and roads
  • Drainage trench covers and drainage pit covers for high strength applications
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Packing & Delivery
Galvanized Steel Grating 30x100mm Mesh 3.0mm Thickness
Frequently Asked Questions
1. Are you factory/manufacturer or trader?

We are direct factory who owns production lines and workers. Everything is flexible and there is no need to worry about extra charges by the middle man or trader.

2. Which countries do you export to?

Our goods are mainly exported to Australia, Canada, UK, USA, Germany, Thailand, South Korea and so on.

3. Can I get free samples?

If the sample is available, yes, can be free. If unavailable, need to customize.

4. What is your minimum order quantity?

Actually there is no MOQ for our products. But usually we recommend a quantity based on the price which is easy to accept.

5. Which payment method you can accept?

Generally we adopt T/T, LC, Western Union, PayPal, Escrow and Money Gram.
