Specifications
Brand Name :
SX-FENCE
Model Number :
3600mm
Certification :
SGS,CE,BV
Place of Origin :
Anping, Hebei, China
MOQ :
50 Sets
Price :
$37/Sets
Payment Terms :
T/T, L/C, Western Union, Cash; etc.
Supply Ability :
10000
Delivery Time :
15-25 days after getting the payment
Packaging Details :
Fence panel: plastic film + metal pallet
Product Name :
358 Security Fence
Frame Material :
Metal
Wire :
3mm, 4mm
Opening :
76.2*12.7mm
Feature :
Anti-climbing
Panel Height :
2.9m
Post Type :
I Post
Brand :
Shengxin
Hole Size :
76.2*12.7mm Or 75*12.5mm
Color :
Yellow
Description

Shear Resistant PVC Coating 4.5mm Anti Climb 358 Security Fence For Jail

358 Security Fence Introduction

358 anti climb fence is extremely difficult to penetrate, with the small mesh aperture being effectively finger proof, and extremely difficult to attack using conventional hand tools. '358' comes from its measurements 3" x 0.5" x 8 gauge which equates to approx 76.2mm x 12.7mm x 4mm in metric.

358 Security Fence Specifications

358 Security Fence
Fence Panel Size section O/A Lenth Total number of fixings Corners-2 clamp bars
Height Height/Width Inters-1 clamp bar

2.0

2007*2515 60*60*2.5mm 2700 7 14
2.4 2400*2515 60*60*2.5mm 3100 9 18

3.0

2997*2515 80*80*2.5mm 3800 11 22
3.3 3302*2515 80*80*2.5mm 4200 12 24
3.6 3607*2515 100*60*3mm 4500 13 26
3.6 3607*2515 100*100*3mm 4500 13 26


358 Security Fence Application

With excellent see through visibility makes anti climb fence very suitable to use on condominium surroundings, schools,business parks, warehouses, power plants etc.

Shear Resistant 4.5mm 358 Security Fencing Jail Wire Fence

358 Security Fence Advantage

1> Designed with special mesh size.

2> Precise and firm welding technique.

3> High strength, difficult to destroyed.

4> High density yet good viewing visibility.

5> Anti-climbing, anti-cutting, anti-corrosion.

6> Easy to install and long service life.

358 Security Fence Installation Details

1> With Barbed Wire

2> With Razor Wire

3> With Spike Top

4> Without Top

Shear Resistant 4.5mm 358 Security Fencing Jail Wire Fence

358 Security Fence Production Flow

1> Material - Straighten & cut short - Welding - Making Curves - Parkerising & Powder coating - Packaging - Container Loading

2> Material - Post Cutting - Making Holes - Powder coating - Packaging

Shear Resistant 4.5mm 358 Security Fencing Jail Wire Fence

358 Security Fence Packing

1> Plastic film at the bottom to avoid the panel be destroyed
2> 4 metal corners to ensure the panel strong and uniform
3> wood plate at the top of pallet to keep the under panel
4> pallet tube size:40*80mm tubes at the botom vertical position

Shear Resistant 4.5mm 358 Security Fencing Jail Wire Fence

Company Introduction

Shengxin is a China-based company. We have nearly 30 years of fence producing experience, and nearly 15 years of exporting experience. Our main products are Single Wire Mesh Fence, Double Wire Mesh Fence, Anti Climb Fence, Chain Link Fence, and also our new product: metal dog cage.

Shear Resistant 4.5mm 358 Security Fencing Jail Wire Fence

Company Advantage

1> We have customers from more than 100 countries, like America, Canada, Mexico, Brazil, Peru, Germany, Russia, France, Poland, Australia, New Zealand, India, Algeria, South Africa, Zimbabwe, PNG, etc.

2> With the location in Anping County, China, it was established in 1992, and then in the year of 1997, Anping County Shengxin Metal Products Co.,Ltd was registered, which has become a well-known established corperation in wire mesh business.

3> We have 11 sets if welding machines, 3 PVC coating production lines, 1 advanced powder coating production line, 2 powder making production lines, and 3 folds marking machines. The production capacity can reach 8,000 square meters per day.

4> With the authentication of ISO 9001, CE, BV, we win our market and get customers' confidednce by abiding conctract, sticking to prestige and strict quality control. We have been enjoying good reputation in both domestic and overseas market

Service

1> Free Sample can be offered
2> Free Drawings can be offered
3> OEM and ODM order are accepted
4> Good Quality + Factory Price + Quick Response + Reliable Service
5> Provide visualization services to view production progress anytime and anywhere
6> Rich exporting market experience offered to enlarge your market
7> Warranty: Best quality products to be manufactured. if the quality is not meet your demand, we are sure to give you full compensation in any way, money back or free reorder.
