The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line
The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line
The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line
The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line
The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line
The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line
Specifications
Warranty :
5 years
Shape :
Octagonal/ 8 sides
Packaging Details :
Bare delivery, Sack Wrap or Fabrics
Load :
500KGF
Delivery Time :
Within 15 working days
Thick :
2.75mm/ 2.9mm/ 3.0mm
Payment Terms :
T/T,L/C
Certification :
ISO 9001
Applied :
15kv distribution power line
MOQ :
1 tons
Galvanizing Thick :
Min average over 86 microns
Height :
35FT
Supply Ability :
1000 tons per month
Surface :
Hot dip galvanized
Brand Name :
Hongxin
Model Number :
HX-35
Price :
800 USD
Place of Origin :
China
Material :
Q355B
Description
The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line
Professional-grade hot-dip galvanized octagonal buried electric steel poles designed to meet Philippines National Electrification Administration standards. These poles feature Q355B material with minimum yield strength of 345MPa and 500kgf load capacity.
Product Specifications
Pole Height: 35FT/10.67M
Type: Direct Buried Type
Segment: 1 Segment
Shape: Octagonal
Material: ASTM A572 GR50/Q355B with min yield strength 345MPa
Manufacturer Profile
Yixing Hongxin Illumination Facilities Co., Ltd - Integrated factory and trading company with over 25 years of experience in manufacturing hot-dip galvanized steel poles. Exporting to Southeast Asia, Africa, Europe, Australia, the Middle East, and South America.
Material Specifications
Raw material conforms to GB/T1591-2008 standard using Q255, Q355, Q420, Q460 steel grades.
China-GB America-ASTM Equivalent
Q255 Grade D SS400, S235JO
Q355 Grade50[345] S355JR
Q420 Grade60[415] S420NL
Q460 Grade65[450] S460NL
Manufacturing Process
Our factory utilizes advanced production equipment including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure superior quality steel poles.
The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line
Product Specifications Table
Philippines NEA Standard Distribution Steel Poles - 25FT to 45FT
Height (ft) Thickness (mm) Butt Diameter (mm) Top Diameter (mm) Design Load (kg) Yield Stress (MPa) Zinc Coating (microns)
25 2.5 152 120 300 345 86
30 3.0 226 127 500 345 86
35 3.0 248 127 500 345 86
40 3.0 317 127 500 345 86
45 4.0 328 127 750 345 86

The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line

Quality Inspection
Professional engineers conduct comprehensive inspections throughout the manufacturing process and before delivery. Testing includes Lab Tests, Workload Tests, Steel Thickness Tests, and Galvanization Thickness Tests to ensure product quality.
The Philippines Nea Standard Hot-dip Galvanized Electric Steel Pole 35FT Q355B with 500KGF Load for Power Distribution Line
Delivery Information
Standard delivery via 40HQ containers with port limit weight of 26 tons per container.
Frequently Asked Questions
1. Are you a manufacturer or a trading company?
We are the direct factory manufacturer and the trading company.
2. Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
3. What are your main products?
Our main products are electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, and wind generation poles.
4. What's your nearest port?
Shanghai Port is our nearest port.
5. What's your payment term?
Normally 30% deposit and rest by TT before shipping, or L/C.
6. What's your delivery time?
Normally within 15 working days. For large quantities during busy periods, approximately one month.
7. What's your price term?
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
