35FT Hot Dip Galvanized Electric Steel Pole with 500KGF Min Break Load for Power Distribution
35FT Hot Dip Galvanized Electric Steel Pole with 500KGF Min Break Load for Power Distribution
35FT Hot Dip Galvanized Electric Steel Pole with 500KGF Min Break Load for Power Distribution
35FT Hot Dip Galvanized Electric Steel Pole with 500KGF Min Break Load for Power Distribution
35FT Hot Dip Galvanized Electric Steel Pole with 500KGF Min Break Load for Power Distribution
35FT Hot Dip Galvanized Electric Steel Pole with 500KGF Min Break Load for Power Distribution
Specifications
Brand Name :
Hongxin
Model Number :
HX-35
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 tons
Price :
800 USD
Payment Terms :
T/T,L/C
Supply Ability :
1000 tons per month
Delivery Time :
Within 15 working days
Packaging Details :
Bare delivery, Sack Wrap or Fabrics
Height :
35FT
Material :
Q355B
Thick :
2.75mm/ 2.9mm/ 3.0mm
Load :
500KGF
Surface :
Hot dip galvanized
Galvanizing Thick :
Min average over 86 microns
Shape :
Octagonal/ 8-sides
Applied :
15kv distribution power line
Warranty :
5 years
Description
35FT Hot Dip Galvanized 8-Sides Electric Steel Pole with 500KGF Min Break Load for Power Distribution Line
Hot-dip galvanized octagonal buried electric steel poles designed to meet Philippines National Electrification Administration standards. These poles feature Q355B material with minimum yield strength of 345MPa and 500kgf min break load capacity.
Product Specifications
Pole Height: 35FT(10.67M)
Type: Direct Buried Type
Segment: 1 Segment
Shape: Octagonal
Material: ASTM A572 GR50/Q355B with min yield strength 345MPa
Manufacturer Profile
Yixing Hongxin Illumination Facilities Co., Ltd - Integrated factory and trading company with over 25 years of experience in manufacturing hot-dip galvanized steel poles. Exporting to Southeast Asia, Africa, Europe, Australia, the Middle East, and South America.
Material Specifications
Raw material conforms to GB/T1591-2008 standard using Q255, Q355, Q420, Q460 steel grades.
China-GB America-ASTM Equivalent
Q255 Grade D SS400, S235JO
Q355 Grade50[345] S355JR
Q420 Grade60[415] S420NL
Q460 Grade65[450] S460NL
Manufacturing Process
Our factory utilizes advanced production equipment including bending calibration machines, hydraulic plate shearing machines, cutting machines, slitting machines, gas welding machines, and hydraulic straighteners to ensure superior quality steel poles.
35FT Hot Dip Galvanized Electric Steel Pole with 500KGF Min Break Load for Power Distribution
Product Specifications Table
Philippines NEA Standard Distribution Steel Poles - 25FT to 45FT
Height (ft) Thickness (mm) Butt Diameter (mm) Top Diameter (mm) Design Load (kg) Yield Stress (MPa) Zinc Coating (microns)
25 2.5 152 120 300 345 86
30 3.0 226 127 500 345 86
35 3.0 248 127 500 345 86
40 3.0 317 127 500 345 86
45 4.0 328 127 750 345 86

35FT Hot Dip Galvanized Electric Steel Pole with 500KGF Min Break Load for Power Distribution

Quality Inspection
Professional engineers conduct comprehensive inspections throughout the manufacturing process and before delivery. Testing includes Lab Tests, Workload Tests, Steel Thickness Tests, and Galvanization Thickness Tests to ensure product quality.
35FT Hot Dip Galvanized Electric Steel Pole with 500KGF Min Break Load for Power Distribution
Delivery Information
Standard delivery via 40HQ containers with port limit weight of 26 tons per container.
Frequently Asked Questions
1. Are you a manufacturer or a trading company?
We are the direct factory manufacturer and the trading company.
2. Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
3. What are your main products?
Our main products are electric poles, street lighting poles, high mast poles, telecommunication tower poles, traffic signal poles, and wind generation poles.
4. What's your nearest port?
Shanghai Port is our nearest port.
5. What's your payment term?
Normally 30% deposit and rest by TT before shipping, or L/C.
6. What's your delivery time?
Normally within 15 working days. For large quantities during busy periods, approximately one month.
7. What's your price term?
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance
