25FT/7620mm Hot-dip Galvanized Octagonal Steel Pole with 300KGF Load for Distribution Lines
25FT/7620mm Hot-dip Galvanized Octagonal Steel Pole with 300KGF Load for Distribution Lines
25FT/7620mm Hot-dip Galvanized Octagonal Steel Pole with 300KGF Load for Distribution Lines
25FT/7620mm Hot-dip Galvanized Octagonal Steel Pole with 300KGF Load for Distribution Lines
Specifications
Brand Name :
Hongxin
Model Number :
HX-25
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 Ton
Price :
800 USD
Payment Terms :
T/T,L/C
Supply Ability :
1000 tons per month
Delivery Time :
Within 15 working days
Packaging Details :
Bare delivery, Sack Wrap or Cloth Wrap
Height :
25FT/7620mm
Shape :
Octagonal/ 8 sides
Material :
Q355/Q235
Thick :
2.5mm/ 3.0mm
Load :
300KGF/ 3kN
Surface :
Hot dip galvanized
Galvanizing Thick :
Min average over 86 microns
Applied :
Power line
Warranty :
5 years
Description
25FT/7620mm Hot-dip Galvanized Octagonal Steel Pole with 300KGF Load for Distribution Lines
The Galvanized Steel Pole is an ideal choice for many outdoor applications. With a length of 7620mm, this 25FT steel pole is made of galvanized steel, giving it a silver color and high corrosion resistance. It has a thickness of 2.5mm and a diameter of 120mm/152mm, making it suitable for a wide variety of uses. With its high corrosion resistance, this 25FT steel pole is perfect for outdoor use, and it is sure to last for many years.
Material Specifications
Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.
China-GB America-ASTM Equivalent
Q255 Grade D SS400,S235JO
Q355 Grade50[345] S355JR
Q420 Grade60[415] S420NL
Q460 Grade65[450] S460NL
Manufacturing Process
Our factory owns advanced production lines and machines including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, hydraulic straightener, etc. All insure us to produce steel poles with best quality.

25FT/7620mm Hot-dip Galvanized Octagonal Steel Pole with 300KGF Load for Distribution Lines

Product Specifications
Steel Pole of National Electrification Administration (PHILIPPINES)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
Height (ft) Thickness (mm) Butt Diameter (mm) Top Diameter (mm) Design Load (kg) Yield Stress (MPA) Zinc Coating (microns)
25 2.5 152 120 300 345 86
30 3.0 226 127 500 345 86
35 3.0 248 127 500 345 86
40 3.0 317 127 500 345 86
45 4.0 328 127 750 345 86
25FT/7620mm Hot-dip Galvanized Octagonal Steel Pole with 300KGF Load for Distribution Lines
Quality Inspection
To ensure the quality, we have professional engineers to inspect the poles during the manufacturing and before delivery.
  • Lab Test
  • Workload Test
  • Steel thickness Test
  • Galvanization thickness Test
Delivery Information
We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are the direct factory manufacturer and the trading company.
Where is your company located?
Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).
What are your main products?
Our main products are electric poles, street lighting poles, high mast pole, telecommunication tower poles, traffic signal poles, wind generation poles, etc.
What's your nearest port?
Shanghai Port is our nearest port.
What's your payment term?
Normally 30% deposit and rest by TT before shipping. Or L/C.
What's your delivery time?
Normally within 15 working days. If our factory is busy and your quantity is large, then around one month.
What's your price term?
Price Term: EXW, FOB, CFR or CIF.
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.
