ASTM A123 Galvanized 10m Medium-Voltage Distribution Steel Pole Pre-Drilled Q235B
ASTM A123 Galvanized 10m Medium-Voltage Distribution Steel Pole Pre-Drilled Q235B
ASTM A123 Galvanized 10m Medium-Voltage Distribution Steel Pole Pre-Drilled Q235B
ASTM A123 Galvanized 10m Medium-Voltage Distribution Steel Pole Pre-Drilled Q235B
Specifications
Supply Ability :
6000 Pieces per Month
Zinc Coating Thickness :
≥86μm (610g/m²)
Pre-Drilled Pattern :
Per customer GA drawing
Bottom Diameter :
300mm
Model Number :
ESP-10M-ST-A123
Price :
USD 95-180 / Piece
Height :
10 meters
Material :
Q235B Structural Steel
Top Diameter :
150mm
Certification :
ISO 9001:2015, ASTM A123
Packaging Details :
Anti-rust oil coating, bundled 5 poles per steel-strapped wooden pallet with inter-layer timber separators
Surface Treatment :
Hot-Dip Galvanized per ASTM A123
Place of Origin :
Jiangsu, China
Delivery Time :
7-15 working days
MOQ :
10 Pieces
Payment Terms :
T/T,L/C
Voltage Level :
11kV / 33kV
Brand Name :
ECER Steel Pole
Wall Thickness :
3.5-6mm
Description

ASTM A123 Galvanized 10m Medium-Voltage Distribution Steel Pole

Product Overview

The ESP-10M-ST-A123 is a cost-optimized distribution pole designed for rapid deployment in 11kV-33kV overhead networks. Manufactured from Q235B structural steel with ASTM A123 hot-dip galvanization, this 10-meter pole features pre-drilled mounting holes that slash field installation time by up to 40%.

ASTM A123 Galvanized 10m Medium-Voltage Distribution Steel Pole Pre-Drilled Q235B

Key Features

  • Pre-Drilled Mounting System: All cross-arm, insulator, and accessory holes CNC-drilled at factory per customer-approved GA drawings with ±1mm positional accuracy
  • ASTM A123 Galvanization: Full-immersion hot-dip process coats interior and exterior surfaces uniformly, providing 86μm minimum zinc thickness for rural and semi-industrial environments
  • Q235B Steel Economy: Proven carbon structural steel with excellent formability and galvanizing response, delivering reliable performance at competitive pricing
  • Rapid Dispatch: Standard models maintained in inventory for 3-day sample shipment; production orders fulfilled in 7-15 working days

Technical Specifications

Parameter Value
Pole Height 10m (embedment 1.6m)
Sections 1
Steel Grade Q235B (Yield 235 MPa)
Top/Bottom Diameter 150mm / 300mm
Wind Zone Up to 140 km/h
HS Code 7308.90

Applications

Budget-optimized solution for rural electrification programs, agricultural power distribution, secondary distribution spurs, temporary construction site power, and utility pole replacement projects where cost-per-kilometer is a primary consideration.

Installation Efficiency

Pre-drilled hole patterns are verified against customer-provided GA drawings using CMM (Coordinate Measuring Machine) inspection. Each pole ships with a matching hole schedule drawing for field crew reference. Typical 3-man crew can erect and outfit a complete pole within 2 hours using standard equipment.
