Erti-4 Titanium Welding Wire Pure Titanium Wire
Erti-4 Titanium Welding Wire Pure Titanium Wire
Erti-4 Titanium Welding Wire Pure Titanium Wire
Erti-4 Titanium Welding Wire Pure Titanium Wire
Erti-4 Titanium Welding Wire Pure Titanium Wire
Erti-4 Titanium Welding Wire Pure Titanium Wire
Erti-4 Titanium Welding Wire Pure Titanium Wire
Erti-4 Titanium Welding Wire Pure Titanium Wire
Specifications
Brand Name :
LHTI
Model Number :
LH-12
Certification :
ISO9001:2015; TUV; SGS;BV
Place of Origin :
China
MOQ :
10 kg
Payment Terms :
L/C, D/P, T/T, Western Union,paypal etc
Supply Ability :
50000 kgs per month
Delivery Time :
In stock--3 days.production--15-20 working days
Packaging Details :
Coil and spool package in carton case or plywood case,straight wire package in Plastic case,outside is standard export plywood case
Product Name :
ERTi 1 ERTi 2 Gr.1 Gr.2 Straight / Coil Ti Pure Titanium Wire Price
Grade :
Grade1 Grade2 ErTi1 ErTi2
Shape :
Coil,spool,straight
Material :
Pure titanium
Surface :
Pickling surface/polish surface
Package :
Standard export package
Hot sale diameter :
0.8mm-5mm etc
Length :
1000mm
Key words :
Thin Titanium wire
Description

Erti-4 Titanium Welding Wire Pure Titanium Wire

Standard:GB,ASTM, BS, BSW, ISO ASTM B863 ASTM B348 ASTM F67 ASTM F136
Material:GR1 GR2 GR3 GR4 GR5 GR7 GR9 GR12
Shape:Straight , spool ,coil
Size:Dia(0.06--6) *L
Surface :pickling, polished, bright finish, etc.
Application:Chemical equipment, such as pipes, heat exchangers, evaporators, heaters, reaction kettles etc

ASTM Base Metal Grade Base metal Normal composition Recommended Filler Metal
UTS(min.) ksi[Mpa] YS(min.) ksi[Mpa]
Grade 1 35[240] 20[138] Unalloyed Ti CP1 ERTi-1
Grade 2 50[345] 40[275] Unalloyed Ti CP2 ERTi-2
Grade 4 80[550] 70[483] Unalloyed Ti CP4 ERTi-4
Grade 5 130[895] 120[828] Ti 6AL-4V ERTi-5
Grade 7 50[345] 40[275] Ti 0.15Pd ERTi-7

AWS CHEMICAL SPECIFICATIONS
AWS A5.16 UNS C O N H I Al V Pd
Number
ERTi 1 R50100 0.03 0.03-0.10 0.012 0.005 0.08 - - -
ERTi 2 R50120 0.03 0.08-0.16 0.015 0.008 0.12 - - -
ERTi 4 R50130 0.03 0.08-0.32 0.025 0.008 0.25 - - -
ERTi 5 R56400 0.05 0.12-0.20 0.03 0.015 0.22 5.5-6.7 3.5-4.5 -
ERTi 7 R52401 0.03 0.08-0.16 0.015 0.008 0.12 - - 0.12-0.25
