Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe
Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe
Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe
Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe
Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe
Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe
Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe
Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe
Specifications
Brand Name :
LH-Ti
Model Number :
Gr2 titanium round seamless pipe and tube
Certification :
ISO9001:2015
Place of Origin :
Shaanxi, China
MOQ :
5 Kg
Price :
$20.00~$30.00/kg
Payment Terms :
L/C, T/T, MoneyGram,Paypal
Supply Ability :
10000 Kilogram/Kilograms per Month
Delivery Time :
10-25 work days
Packaging Details :
First, packaging with moisture-proof paper; Second, packaging with kraft paper; Third, packaging with foam plastics in all side of plywood case.
Standard :
ASTM
Technique :
Seamless, Cold Drawn
Processing Service :
Bending, Welding, Decoiling, Cutting, Punching
Material :
Titanium
Grade :
Titanium, Gr2 Gr5 Gr7 Gr9 Gr12
Application :
Industrial
Outer Diameter :
10-300mm
Inside Diameter :
4~268mm
Description

Gr9 Titanium Tubes For Titanium Bicycle Frame Titanium Pipe

Outside diameter:≤60mm
Wall thickness:≥0.5mm
Length:60~1000mm(normal szie)
Technique: Cold Rolled, hot rolled
Grade: GR9 Ti3AL2.5V

Application: Exhaust pipes for automobiles, exhaust pipes for motorcycles, bicycle racks, oil pipes, titanium pipes in the aviation field, etc.titanium frame builders,lynskey bike frames,guru titanium bikes,titanium single speed mountain bike,titanium frame gravel bike,titanium road bike frame

Chemical requirements
N C H Fe O Al V Pd Mo Ni Ti
Gr1 0.03 0.08 0.015 0.20 0.18 / / / / / bal
Gr2 0.03 0.08 0.015 0.30 0.25 / / / / / bal
Gr5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal
Gr7 0.03 0.08 0.015 0.30 0.25 / / 0.12~0.25 / / bal
Gr12 0.03 0.08 0.015 0.30 0.25 / / / 0.2~0.4 0.6~0.9 bal

Tensile requirements
Grade Tensile srength(min) Yeild strength(mm) Elongation(%)
KSI MPa Ksi MPa
1 35 240 20 138 24
2 50 345 40 275 20
5 130 895 120 828 10
7 50 345 40 275 20
12 70 438 50 345 18
