Specifications
Brand Name :
LH
Model Number :
LHTB
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
10kg
Price :
USD15-28/kg
Payment Terms :
L/C, T/T, Western Union, MoneyGram, D/P, D/A
Supply Ability :
50000kg per month
Delivery Time :
7-20days
Packaging Details :
Standard export packing
Product name :
Titanium bar Titanium rod
Surface :
Polished, forged
Size :
Customized
Grade :
Ti alloy GR5
Application :
Industrial
Density :
4.51 G/cm^3
Description

ASTM B348 Gr5 12mm*1000mm Titanium rod for producing automotive screws

High-quality Titanium rod has low density, lightweight, high strength, also has good corrosion resistance,

high-temperature resistance, low-temperature resistance, acid resistance, alkali resistance, and so on.

1. Product Information

Product name type
Pure Titanium bar/Pure Titanium rod/Titanium alloy bar/Titanium alloy rod
Standard
ASTM B348/ASME SB348, ISO-5832-2(3), AMS4928, MIL-T-9047G, JIS etc
Titanium Type
Titanium alloy
Grade

Gr5

Diameter
5-350mm
Length
Max6000mm
Technique
Forging, Machining
Surface
Acid surface or polishing, sandblasted surface
Shape
Round, flat, square, hexagonal
Application
Metallurgy, electronics, medical, chemical, petroleum, pharmaceutical, aerospace, etc.

2. Chemical requirements

N C H Fe O Al V Pd Mo Ni Ti
Gr5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal

3. Physical Properties

Physical Properties
Tensile Strength(min) Yield Strength(min) Elongation(%)
ksi MPa ksi MPa
Grade 5 130 895 120 828 10


4.Tolerance

Diameter(mm) h7 h8 h9 h10 h11 h12
Tolerance precision (um)
3~6 12 18 30 48 75 120
6~10 15 22 36 58 90 150
10~18 18 27 43 70 110 180
"h"stands for a tolerance range(-x,+0),on the contrary,"H"stands for a tolerance(-0,+X)

Row material

Baoji Lihua Non-ferrous Metals Co., Ltd

Baoji Lihua Non-ferrous Metals Co., Ltd.

As a leading manufacturer of titanium products for over 14 years, we supply a series of high-performance products for titanium products, including titanium tube, titanium bar, and titanium wire, etc.

Relevant & Customized Titanium Products are welcomed.

Cooperation with us will provide you a strong guarantee


1.ISO9001:2015
2. The timely delivery rate is 99.8%, sometimes in advance.
3.Excellent after-sale service.
4.Rapid inquiry reply, within 2 hours.
5.Fair payment term
6.Professional technical adviser
7.Material certificate
8.Quality is strictly according to ASTM,DIN,UNS,GB/T standard(manufacturing process,surface treatment,inspections and testing).
