Specifications
Brand Name :
VANFORGE
Certification :
ISO9001, ISO10012, ISO14001, OHSAS18001, ABS, BV, DNV, Lloyd, NK, PED
Place of Origin :
China
MOQ :
500 kg
Payment Terms :
L/C, T/T
Supply Ability :
1000 metric tons per month
Delivery Time :
30 days
Packaging Details :
Seaworthy package for export
Material :
Austenitic stainless steel 316
Process :
Cold drawn steel wire
Type :
In strands
Surface :
Metallic bright
Shape :
Round
Length :
On request
Feature :
Corrosion resisitant, wear resisitant
Price :
Negotiable
Description

1x19 high breaking load AISI316 stainless steel wire rope for marine industry

VANFORGE supply a large range of marine grade wire ropes that are suitable for all marine industry applications.

1x19 AISI316 stainless steel strand is a very popular stainless steel construction. Used heavily throughout the marine industry, 1x19’s excellent breaking load and low stretch characteristics along with its’ aesthetic appeal make it a favorite for marine, structural and balustrade applications as well as many others, examples of which are shown below:

Applications

Balustrades

Standing rigging

Mast stays

Guardrail

Structural

Stay wires

Marine/Saltwater environment

Sewage treatment works

Breaking loads

Nominal diameter Approximate mass Minimum breaking loads – 1570 MPa
mm kg/m kN kN
2.0 0.019 3.14 320
2.0 0.030 4.90 499
3.0 0.043 7.06 719
4.0 0.078 12.6 1284
5.0 0.122 19.6 1998
6.0 0.176 28.2 2875
7.0 0.239 34.8 3548
8.0 0.312 45.5 4639
9.0 0.395 57.6 5873
10.0 0.488 71.1 7250
11.0 0.591 86.0 8769
12.0 0.703 102.0 10401
14.0 0.957 139.0 14174
16.0 1.250 182.0 18558
19.0 1.760 212.0 21617
22.0 2.360 285.0 29061
26.0 3.300 398.0 40584

1x19 Balustrades Stainless Steel Wire Rope High Strength Anti Corrosion

1x19 Balustrades Stainless Steel Wire Rope High Strength Anti Corrosion
