ASTM A240 316 Embossed Stainless Steel Sheet 0.6mm-3.0mm Thickness Linen Leather Pattern for Anti-Slip Flooring Systems
ASTM A240 316 Embossed Stainless Steel Sheet 0.6mm-3.0mm Thickness Linen Leather Pattern for Anti-Slip Flooring Systems
Specifications
Packaging Details :
Laser PE protective film on embossed surface, interleaved with craft paper, packed in reinforced export plywood cases
Model Number :
SS-ES-316
Certification :
ISO 9001:2015, CE, SGS, Slip Resistance Test
Thickness :
0.6mm - 3.0mm
Steel Grade :
316 (UNS S31600)
Payment Terms :
T/T,L/C,Western Union
Pattern Depth :
0.03mm - 0.08mm
Pattern Type :
Linen, Leather, Diamond, Stone
Slip Resistance :
R10-R12 (DIN 51130)
Length :
2438mm, 3048mm, or Custom Cut
Supply Ability :
30000 Sheets per Month
Width :
1219mm, 1500mm
Delivery Time :
7-12 working days for stock, 15-25 days for production
Price :
USD 30-70 / Sheet
Standard :
ASTM A240 / ASME SA240
Place of Origin :
Zhejiang, China
Brand Name :
ECER
MOQ :
50 Sheets
Description
Product Introduction

This ASTM A240 316 embossed stainless steel sheet combines functional safety with aesthetic design through precision-engineered surface texturing. The linen and leather embossing patterns create raised micro-textures that significantly increase surface friction, achieving R10-R12 slip resistance ratings per DIN 51130 without compromising the sheet's structural integrity. The 316 grade with molybdenum addition provides essential corrosion resistance for outdoor, marine, and chemically aggressive environments where standard 304 would be insufficient. Embossing also increases sheet rigidity, allowing for thinner gauge material in certain applications while maintaining structural performance.

Product Specifications
Parameter Specification
Product Type Embossed Stainless Steel Sheet
Standard ASTM A240 / ASME SA240
Steel Grade 316
Thickness 0.6mm - 3.0mm
Width 1219mm, 1500mm
Length 2438mm, 3048mm, or Custom Cut
Pattern Type Linen, Leather, Diamond, Stone
Pattern Depth 0.03mm - 0.08mm
Slip Resistance R10-R12 (DIN 51130)
Inspection Visual, Pattern Uniformity, Slip Test, Corrosion Test
Chemical Composition (wt%)
Parameter Specification
Carbon (C) ≤0.08
Manganese (Mn) ≤2.00
Silicon (Si) ≤1.00
Phosphorus (P) ≤0.045
Sulfur (S) ≤0.030
Chromium (Cr) 16.0-18.0
Nickel (Ni) 10.0-14.0
Molybdenum (Mo) 2.0-3.0
Mechanical Properties
Parameter Specification
Tensile Strength ≥515 MPa
Yield Strength ≥205 MPa
Elongation ≥40%
Hardness ≤217 HBW / ≤95 HRB
Application Areas

Industrial anti-slip flooring and platforms, Offshore platform walkway surfaces, Food processing plant flooring, Marine vessel deck surfaces, Chemical plant access walkways, Stair treads and step nosings, Commercial kitchen flooring systems, Loading dock and ramp surfaces
