Specifications
Brand Name :
Baosteel,TISCO
Model Number :
201 / 202 / 301 / 302 / 303 / 304 / 304L / 305 / 309S / 310S / 316 / 316L / 317 / 317L / 321 / 347 / 409L / 410 / 420 / 430 / 440C / 2205 / 2507
Certification :
EN 10204 Type 3.1 / 3.2 available
Place of Origin :
MADE IN CHAINA
MOQ :
100kg
Price :
Negotiable (Request a Quote)
Payment Terms :
T/T,D/P,D/A,Western Union,PayPal
Supply Ability :
10000tons
Delivery Time :
15-25days
Packaging Details :
Wooden pallets, wooden crates, woven bags, etc.
Country of Origin :
MADE IN CHAINA
Brand :
Baosteel,TISCO
Certifications :
ISO/EN 10204 Type 3.1 / 3.2 available
Grade :
201 / 202 / 301 / 302 / 303 / 304 / 304L / 305 / 309S / 310S / 316 / 316L / 317 / 317L / 321 / 347 / 409L / 410 / 420 / 430 / 440C / 2205 / 2507 / 630 (17-4PH)
MOQ :
100kg
Packaging :
Wooden Case / Wooden Pallet / Steel Frame / Carton / Woven Bag
Supply Capacity :
10000tons
Description

Stainless steel anti-slip flooring plate features a raised diamond pattern on the surface. This design provides excellent traction and slip resistance in wet, oily, or high-traffic environments.

Our anti-slip flooring plates are manufactured from high-grade stainless steel, offering superior corrosion resistance, high strength, and easy maintenance. They are the preferred choice for safety-critical flooring applications across multiple industries.

Product Specifications
Parameter Details
Standard ASTM A240, EN 10088, JIS G4305, GB/T 4237
Grades 201, 304, 304L, 316, 316L, 430
Thickness 1.2 mm – 6.0 mm
Width 1000 mm, 1219 mm, 1240 mm, 1500 mm (custom available)
Length 2000 mm – 6000 mm (cut to size available)
Surface Finish 2B (cold rolled), No.1 (hot rolled), HL (hairline)
Pattern Type Diamond (standard), lentil, round bean
Pattern Height 0.6 mm – 1.2 mm
Chemical Composition (Reference %)
Element Grade 304 Grade 316 Grade 201
Carbon (C) ≤ 0.08 ≤ 0.08 ≤ 0.15
Silicon (Si) ≤ 1.00 ≤ 1.00 ≤ 1.00
Manganese (Mn) ≤ 2.00 ≤ 2.00 5.5 – 7.5
Phosphorus (P) ≤ 0.045 ≤ 0.045 ≤ 0.050
Sulfur (S) ≤ 0.030 ≤ 0.030 ≤ 0.030
Chromium (Cr) 18.0 – 20.0 16.0 – 18.0 16.0 – 18.0
Nickel (Ni) 8.0 – 10.5 10.0 – 14.0 3.5 – 5.5
Molybdenum (Mo) 2.0 – 3.0
Mechanical Properties
Grade Tensile Strength (MPa) Yield Strength (MPa) Elongation (%)
304 ≥ 515 ≥ 205 ≥ 40
316 ≥ 515 ≥ 205 ≥ 40
201 ≥ 620 ≥ 310 ≥ 30

Note: The values above are for reference only. Please refer to the mill test certificate for actual data.

Key Features
  • Superior Slip Resistance – Raised diamond pattern provides excellent traction

  • Corrosion Resistant – Performs well in wet, humid, and chemical environments

  • High Strength – Withstands heavy foot and vehicle traffic

  • Easy to Clean – Smooth base surface and raised pattern resist debris buildup

  • Low Maintenance – Does not require painting or coating

  • Hygienic – Non-porous surface prevents bacterial growth

  • Fire Resistant – Non-combustible material

Applications

Stainless steel anti-slip flooring plate is suitable for safety-critical flooring applications:

Industrial Facilities

  • Factory walkways and platforms

  • Machine shop flooring

  • Warehouse aisles

  • Chemical plant floors

  • Oil and gas platform decks

Commercial Buildings

  • Shopping mall entrances and stair treads

  • Hotel pool decks and ramps

  • Hospital walkways

  • School entryways

  • Restaurant kitchen floors

Transportation

  • Bus and train entry steps

  • Truck and trailer flooring

  • Ferry and ship decks

  • Airport walkways

  • Loading dock plates

Public Infrastructure

  • Subway station platforms

  • Bridge walkways

  • Pedestrian overpasses

  • Park ramps and footpaths

  • Public restroom flooring

Food & Beverage

  • Food processing plant floors

  • Commercial kitchen flooring

  • Brewery walkways

  • Dairy facility floors

  • Slaughterhouse flooring

Grade Selection Guide
Environment Recommended Grade
Dry indoor areas 201 or 304
Wet areas with fresh water 304
Food processing / hygiene critical 304
Coastal / salt spray exposure 316
Chemical / chloride exposure 316
High temperature areas 304L or 316L
High traffic / heavy load 304 or 316 (thicker gauge)
