Specifications
Brand Name :
Jinye
Model Number :
HSJY-6.35 x 1650
Certification :
ISO2009
Place of Origin :
Wuxi, China
MOQ :
1Set
Payment Terms :
L/C, T/T
Supply Ability :
10sets yearly
Delivery Time :
150-180days
Packaging Details :
Machine in nude, parts in package
Product name :
High Strength 1400Mpa Steel Coil Slitting Line
Coil Roll Thickness :
0.8-6.35mm
Number Of Strip :
max 30strips
Warranty :
1 year
Slitting Width :
300-1650mm
Recoiling Diameter :
φ508mm
Double Slitters :
Optional
Coil Material :
Pickled plate, cold rolled plate, high-strength stee
Slitter Arbor :
280mm
Total Power :
600KW
Slitting speed :
max 150m/min
Steel coil weight :
max 25T
Description

High Strength 1400Mpa Steel Coil Slitting Line Slitter Machine Manufacturer

High strength steel has high tensile and yield strength, its tensile strength at least 540Mpa up to 1400Mpa. Our high speed slitting line specially designed for high strength steel coil slitting is competitive, efficient and convenient. Here introduce the popular model 6.35 x 1650mm slitting line as example. To know more about the slitter machine, you can contact us to communicate further.

Specification:

Raw material Finished product

Material: Pickled plate, cold rolled plate, high-strength steel.
Coil Thickness:

0.8mm - 6.35mm, for pickled, Cold rolled plate
0.8mm - 1.6mm, for high-strength steel Cold rolled plate
Coil Width: Min 400mm - 1,650mm
Coil Weight: Max 25,000 kg
Coil Inner Diameter (I.D.): φ508 / φ610 mm
Coil Outer Diameter (O.D.): Max φ2,100mm Min φ1,000 mm

Thickness: 0.8-1.6mm TS: Max 1200MPa, YS: Max 1000 MPa Thickness 1.6-4.0mm TS: Max 780 MPa, YS: Max 650 MPa

Finished Width:

Min 30mm ~ Max 1,650mm
Max Number of Strips: Max 30 strips
Minimum Edge Trim Width: 2 times material thickness, but not less than 2mm min.

Finished Product Inner Diameter:
φ508 / φ610 mm
Max Finished Coil Weight: 25,000kg

Slitting Speed:

Below 3.0mm thickness: 150 m/min
4.0mm ~ 6.0mm thickness: 80 m/min

Slitting accuracy: ≤ ±0.10mm

Edge Burr: ≤ 3% thickness

Coiling edge Misalignment:≤ ±1.0mm

Coiling Telescoping :≤ ±2.0mm

Camber Accuracy ≤ 1.0mm/m

Machine Making Requirements:

  1. Steel plates for the machine body must be from well-known domestic steel mills.
  2. Welding requirements: When welding two steel plates, the weld height should be 2/3 of the thinner plate's thickness. The weld surface should be smooth, without slag and spatter, etc.
  3. All welded parts must be sandblasted or shot blasted.
  4. Main parts and components of the uncoiler, slitter, and recoiler must undergo annealing treatment. The heat treatment process must guarantee the required time to completely remove stress. Machining must be done on CNC machining centers with accurate tolerance fits.
  5. Machining process: When machining workpieces, the machine table must be cleaned. If necessary, use an oilstone to remove raised parts on the table. The workpiece must be firmly supported. The final process should involve stress relief. According to the six-point positioning principle, use dial indicators in three directions on the workpiece during machining to check for looseness.
  6. All sharp edges must be chamfered.
  7. Topcoat must be applied at least twice. Topcoat paint must be from well-known domestic or international brands.

Composition:

No. Item Name Qty Remarks
1 Mechanical Equipment 1 Lot
1.1 Preparation Table 1 set 2 stations
1.2 Loading Car with movable cover plate 1 set
1.3 Uncoiler (with remote control), φ508 to φ610 hydraulic mandrel, paper winder 1 set
1.4 Uncoiler Infeed Guide Plate 1 set
1.5 Pinch Roll, 5rolls Leveler, Hydraulic Head Shear and Scrap Box 1 set
1.6 Entry Loop (or Accumulator) 1 set
1.7 Single Knife Holder Slitter + Auto Knife Change + Robot Knife Setting + Knife Library (with remote control) 1set
1.8 Offline Horizontal Scrap Winder 2 sets Left and right sides
1.9 Exit Loop Component and Transfer Platform 1 set
1.10 Dual Separator Shaft and Tension Device 1 set
1.11 Outfeed Power Pinch Roll, Hydraulic Dividing Shear, Rear Deflector Roll 1 set
1.12 Recoiler (with remote control), Slow Rise Device, Mandrel Support + Paper Unwinder 1 set
1.13 Unloading Car, Cross Arm Turnstile 1 set each
1.14 Hydraulic System Unit 1 Lot
1.15 Pneumatic System Unit 1 Lot
1.16 Special Tools 1 Lot
1.17 Other Necessary Equipment and Devices 1 Lot
1.18 Safety Fencing around Equipment 1 Lot
2 Electrical Automation Control Equipment 1 Lot
2.1 Control System Hardware & Software (incl. hardware user manual (at least electronic version) and commissioning software) 1 set
2.2 Connecting cables from control cabinet to equipment and between equipment, and special cables (power and control cables) 1Set
3 Commissioning Spare Parts
3.1 Blades, spacers, etc. for commissioning 1lot
