Specifications
Brand Name :
Xrido
Model Number :
Customizable
Certification :
CE ISO
MOQ :
1
Delivery Time :
5-30 word days
place of origin :
Henan, China
brand name :
Xrido
model number :
ESS-600-1600
type :
Magnetic Separator
warranty :
1 Year
material :
Export Wooden Packing
machinery test report :
Provided
video outgoing-inspection :
Provided
core components :
Pressure vessel, motor, Bearing, Gear, PLC, Pump, Engine
weight (kg) :
2000 kg
Product name :
Eddy Current Separator Non Ferrous Metal Separator
Application :
Nonferrous separation
Machine type :
waste sorting machine
After Warranty Service :
Field Maintenance
Advantage :
Easy Operation High Efficiency
Raw material :
Ubran Waste Garbage
Separation rate :
98-99%
Function :
Garbage Recycling Sorting
Production Capacity :
2500-4500 KG/H, ≥20T/H
Voltage :
380V(can customized)
Condition :
New
Showroom Location :
None
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Applicable Industries :
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Food Shop, Construction works , Energy & Mining, Other
Power :
26.7-79
Description
Products Description

The non-ferrous metal separator uses rare earth permanent magnets to induce eddy currents into metal particles during operation. The repulsive force generated by the eddy currents separates metals from non-metals, providing a cleaner product for subsequent processing. The removal of metals is selective and minimizes product loss.

The non-ferrous metal separator consists of an external drum, an internal permanent magnet rotor, a drive unit and a belt conveyor. The external drum shell is made of non-metallic composite materials and rotates at conventional belt conveyor speeds. The internal rare earth alternating polarity rotor rotates at a much higher speed than the external drum shell.

Through the induction of eddy currents and the resulting repulsive force, the alternating magnetic field selectively repels non-ferrous metals and physically separates them from other materials while minimizing product loss.

PET Flakes Separator Non- Ferrous Metal Separator Scrap Aluminum Copper Plastic Eddy Current Separator
PET Flakes Separator Non- Ferrous Metal Separator Scrap Aluminum Copper Plastic Eddy Current Separator


Product Paramenters
Model Flat belt conveyor(HP) Polar wheel drum(HP) workload (Kg) vibrating screen(HP) number of machines
X600 2 (1.5kW) or 3 (2.3kW) 7.5 (5.6kW) 400~800 1/2 2
X800 2 (1.5kW) or 3 (2.3kW) 10 (7.5kW) 500~1000 1/2 2
X1000 2 (1.5kW) or 3 (2.3kW) 10 (7.5kW) 600~1200 3/4 2
X1200 2 (1.5kW) or 3 (2.3kW) 10 (7.5kW) 700~1400 3/4 2
X1500 2 (1.5kW) or 3 (2.3kW) 15 (11.3kW) 800~1600 1 2
X1800 2 (1.5kW) or 3 (2.3kW) 15 (11.3kW) 1000~2000 1 2

Key Features and Benefits of the Eddy Current Separator
• Precision Engineering: Our separator is manufactured with precision to ensure high-speed rotor operation with minimal vibration. The rotor spins at up to 3000 RPM, capable of handling even the smallest electronic components.

• Powerful Eddy Currents: Equipped with high-performance magnets, our separator generates a powerful magnetic field of up to 3000 Gauss, ensuring efficient and precise metal separation.

• Durable and Efficient Separation System: Our advanced separation system accurately identifies and separates non-ferrous metals like aluminum, copper, and zinc, handling a wide range of waste materials.

• Automated Control: The fully automated control system minimizes operator error and ensures optimal performance, reducing downtime and operating costs.

• Environmental Friendly: Our separator features a fully enclosed design to reduce dust emissions and maintain a clean working environment, contributing to a sustainable future.

Product Application
• Electronic waste recycling: Separate valuable metals from electronic scrap.
• Automotive recycling: Recover non-ferrous metals from end-of-life vehicles.
• Metal shredding: Process shredded metal to extract valuable materials.
