Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Specifications
Brand Name :
Xrido
Model Number :
Customizable
Certification :
CE ISO
MOQ :
1
Delivery Time :
5-30 word days
place of origin :
Henan, China
brand name :
Xrido
model number :
AT-ES600
type :
Magnetic Separator
warranty :
1 Year
material :
Export Wooden Packing
machinery test report :
Provided
video outgoing-inspection :
Provided
core components :
Pressure vessel, motor, Bearing, Gear, PLC, Pump, Engine
weight (kg) :
2000
Power :
Customized
Product name :
Eddy Current Separator Non Ferrous Metal Separator
Application :
Nonferrous separation
Machine type :
waste sorting machine
After Warranty Service :
Field Maintenance
Advantage :
Easy Operation High Efficiency
Raw material :
Ubran Waste Garbage
Separation rate :
98-99%
Function :
Garbage Recycling Sorting
Production Capacity :
2500-4500 KG/H
Voltage :
380V(can customized)
Description
Products Description
Eddy Current Separator (Non-Ferrous Separator) is to separate non-ferrous metals by the induction principle (eddy current) of a high-frequency magnetic field. The powerful moving magnetic field on the surface of the drum is generated when the powerful permanent magnet inside the drum rotates at high speed, separating three types of materials: iron, non-metal, and nonferrous metals such as aluminum and copper.

The permanent magnet drum of high capability rotating inside the conveyor belt at high speed induces the eddy current in non-magnetic nonferrous metals moving on the drum to generate a magnetic field. This force is exerted in the opposite direction to gravity, and nonferrous metals bounce off by repulsive power from mixed wastes during movement on the conveyor belt. Non-Ferrous metals with larger surface areas, lighter weight and higher conductivity are usually well separated. The separator requires virtually no maintenance and guarantees the stable separation for long-term operation. The Non-Ferrous Separator is installed together with a permanent magnetic separator on MSW to play an important role for sorting waste.

Separating nonferrous metals from wastes.

Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
Product Paramenters
Model Flat belt conveyor(HP) entrance size (mm / in) Polar wheel drum(HP) workload (Kg) vibrating screen(HP) number of machines
X600 2 (1.5kW) or 3 (2.3kW) 600 / 23.6 in 7.5 (5.6kW) 400~800 1/2 2
X800 2 (1.5kW) or 3 (2.3kW) 800 / 31.5 in 10 (7.5kW) 500~1000 1/2 2
X1000 2 (1.5kW) or 3 (2.3kW) 1000 / 39.4 in 10 (7.5kW) 600~1200 3/4 2
X1200 2 (1.5kW) or 3 (2.3kW) 1200 / 47.2 in 10 (7.5kW) 700~1400 3/4 2
X1500 2 (1.5kW) or 3 (2.3kW) 1500 / 59 in 15 (11.3kW) 800~1600 1 2
X1800 2 (1.5kW) or 3 (2.3kW) 1800 / 70.9 in 15 (11.3kW) 1000~2000 1 2
Product Application
Applicable of Waste Sorting System
1.E waste (for appliance waste dismantling)
2.Aluminum beverage can mixed with plastic bottle
3.Ferrous metal with glass
4.Ferrous metal with plastic
5.Ferrous metal with paper
6.Ferrous metal with rubber





When the conductive non-ferrous metal passes through the magnetic field, an eddy current will be induced in the non-ferrous metal, and the eddy current separator itself will produce a direction opposite to the original magnetic field. Non-ferrous metals (such as copper, aluminum, etc.) will jump forward along the conveying direction due to the repulsive force of the magnetic field to achieve separation from other non-metallic substances and achieve the purpose of sorting; its main distinguishing criterion It is the ratio of the conductivity and density of the material. The higher ratio is easier to separate than the lower ratio.

Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter

Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter




Copper Plastic Glass Sorter Equipment Automatic Strong Magnetic Separator Eddy-current Separator Eddy Current Metal Sorter
