Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Specifications
Certification :
CE ISO TUV
Brand Name :
Xrido
Model Number :
Customizable
MOQ :
1 set
Delivery Time :
5-30 word days
place of origin :
Henan, China
plastic type :
PVC, PET, ABS, PP/PE, PE, PP, PC, PMMA, PA, PS
brand name :
Xrido
shaft design :
Double
voltage :
380V, 220V
dimension(l*w*h) :
Custom
power (kw) :
55
weight (t) :
5
warranty :
1 Year
key selling points :
Multifunctional
machinery test report :
Provided
video outgoing-inspection :
Provided
core components :
Bearing, motor, Gear, PLC, Pressure vessel, Engine, Gearbox, Other
Product name :
Double Shaft Waste Shredder Machine
Input Size :
200-2200mm
Advantage :
Easy Operation High Efficiency
Machine Type :
Support Customization
Output :
Compact
Application :
Metal,Plastic,Rubber,Copper,Wood,Fabric
Final product :
1-10 Cm
MOTOR :
Famouse Brand
Color :
Client's Requirements
Description
Products Description
Plastic shredder is the core pre-treatment equipment in the field of plastic recycling. It is mainly used to decompose various types of waste plastic products into small fragments or particles for subsequent melting and regeneration or direct processing and utilization. Plastic shredder uses mechanical shear force to crush plastic waste. It is suitable for processing large-diameter pipes (such as PE pipes), bundled films, plastic containers (bottles, barrels, boxes, etc.) and industrial scraps, etc. 26. Compared with traditional crushers, its blade shaft speed is lower, energy consumption is lower, and it can handle high-toughness materials (such as plastic ropes and films).
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine


Model

Power

(kw)

 Crushing cavity size (mm)

blade diameter

(mm)

 capacity (kg/h)

blade thickness

(mm)

 Weight (t)
SZ-600 15×2 600×480 220 600-1000 15/20/30/40/50 3.2
SZ-800 22×2 800×680 320 1000-1500 20/40/50 4.5
SZ-1000 30×2 1000×680 320 2000-3000 20/40/50 5.6
SZ-1200 37×2 1200×850 400 3000-5000 20/40/50/80/100 9.8
SZ-1500 45×2 1500×850 400 5000-8000 20/40/50/80/100 15
SZ-1800 75×2 1800×1200 500 8000-12000 30/50/100/150/200 21
SZ-2000 90×2 2000×1500 600 12000-18000 50/100/150/200 29
SZ-2200 110×2 2200×1500 600 15000-25000 50/100/150/200 36

Advantages of plastic crusher:
1. Processing materials: Plastic shredders are more focused on the processing of plastic materials, while crushers are suitable for a wider range of material types,
2. Discharge particle size: Plastic shredders have a larger discharge particle size, which is suitable for occasions that require larger particle sizes; crushers have a smaller discharge particle size, which is suitable for occasions that require fine particle sizes.
3. Efficiency and energy consumption: Crusher usually has higher crushing efficiency, but the energy consumption is also relatively high; plastic shredders adopt a low speed, high torque design, and lower energy consumption.
4. Safety and environmental protection: Plastic shredders perform better in safety, noise control and dust pollution; crushers pay more attention to crushing efficiency and structural robustness.


Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Product Application
Plastic shredders are suitable for the treatment of various types of plastic waste, which are specifically classified as follows:
1. Hard plastic products ‌
Plastic sheets (ABS, PE, PP boards, etc.)
Plastic pipes (PE pipes, PVC pipes, silicon core pipes, etc.)
Plastic containers (barrels, boxes, bottles, cans, etc.) ‌
2. Soft/tough plastics ‌
Plastic films (agricultural mulch, packaging films, plastic bags, etc.)
Plastic cords, woven bags, ton bags, etc. ‌
3. Composite Plastic waste ‌
Industrial scraps, injection molding waste, nozzle materials, etc.
Mixed plastic waste (such as waste electrical appliance housings, cable sheaths, etc.)
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine

Successful Project
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Waste Plastic Bucket Trash Can Big Blue Bucket Shredder Machine
Our Advantage
1. It has the characteristics of low speed, high torque and low noise. It is controlled by PLC. It has the functions of starting,stopping, reversing and overloading automatic reversing.
2. The motor + reducer drives the cutter shaft to achieve the shearing effect of low speed and high torque.
3. Bearing six-fold seal, effective waterproof and dust-proof, prolong the service life of bearings.
4. After tool wear, the repair technology of tool coating and welding is adopted to realize the repeated use of the tool, which greatly reduces the maintenance cost of the tool.
5. Separate box design, can easily and quickly remove the entire axle (axle, blade, bearing, sealing system).
6. Tools are arranged according to helix to achieve high efficiency cutting.
7. Both the inner hole and the spindle face of the cutter are designed in hexagonal form to realize the uniformity of the force exerted on the cutter.
8. According to different materials and product shapes to be torn up, different types of cutters can be selected.
