Specifications
Certification :
CE ISO TUV
Price :
CN¥45,374.96/sets 1-4 sets
Brand Name :
Xrido
Model Number :
Customizable
MOQ :
1 set
Delivery Time :
5-30 word days
place of origin :
Henan, China
plastic type :
PVC, PET, ABS, PP/PE, PE, PP, PC, PMMA, PA, PS
brand name :
Xrido
shaft design :
Double
voltage :
110V, 220V, 400V , 380V, 440V, 415V
dimension(l*w*h) :
Custom
power (kw) :
55
weight (t) :
5
warranty :
1 Year
key selling points :
High Productivity
machinery test report :
Provided
video outgoing-inspection :
Provided
core components :
Bearing, motor, Gear, Pump, PLC, Pressure vessel, Engine, Gearbox, Other
Product name :
Double Shaft Waste Shredder Machine
Motor Type :
AC Motor
After Warranty Service :
Field Maintenance
Advantage :
Easy Operation High Efficiency
Function :
Scrap Metal Shredding
Output Sizes :
≥5mm or customized
Input Materials :
Scrap steel iron,card body,cans,bicycle body,etc.
Color :
Customer's Requirement
Machine Type :
Support Customization
Description
Plastic Recycling Textile Jeans Cloth Waste Fabric Shredder Machine
Products Description
Textile shredder ‌ is a mechanical equipment specially used to process waste textiles (such as clothing, bed sheets, plush toys, etc.). It uses mechanical forces such as shearing and tearing to break large-volume textiles into small particles or fibrous materials, which is convenient for subsequent sorting or preparation of RDF fuel. The core equipment includes a double-shaft/single-shaft shredder, which can solve the problem of cloth winding and realize continuous processing.
The Double Shaft Shredder can meet the waste recycling requirements of various industries, and is suitable for shredding thick and difficult materials, such as: electronic waste, plastic,tire, metal, wood, waste rubber, packaging barrels, pallets, etc.
440V 415V Garment Shredder Waste Fabric Shredder Machine Customized
Technical Parameters
Specification XRD-600 XRD-800 XRD-1000 XRD-1200 XRD-1500 XRD-1800 XRD-2000 XRD-2200
Total Weight (t) 3.2 4.5 5.6 9.8 15 21 29 36
Power (kW) 15×2 22×2 30×2 37×2 45×2 75×2 90×2 110×2
Dimensions (L×W×H) (mm) 2800×1300×1850 3000×1300×1850 3300×1500×2200 3600×1800×2200 4180×2000×2400 5800×2400×2800 6400×2700×3000 6800×2700×3200
Crushing Chamber (mm) 600×480 800×680 1000×680 1200×850 1500×850 1800×1200 2000×1500 2200×1500
Blade Diameter (mm) 220 320 320 400 400 500 600 600
Capacity (kg/h) 600-1000 1000-1500 2000-3000 3000-5000 5000-8000 8000-12000 12000-18000 15000-25000
Advantages of leather shredders
Textile shredders have a wide range of applications, mainly covering the following aspects:
Garbage disposal: Textiles are one of the common garbage components in the garbage disposal process. Textile shredders can be used to shred textile waste into small pieces, which is convenient for subsequent landfill, incineration or composting, reducing the volume of garbage and improving processing efficiency.
‌Resource recycling: Textile shredders can convert discarded textiles into reusable resources, such as fibers, filling materials, etc. These materials can be used to make new textiles, furniture, building materials, etc., to achieve resource recycling and reduce dependence on primary resources.
Energy field: In some cases, textile waste can also be used as a source of biomass energy. After the waste is shredded by a textile shredder, it can be used together with other biomass materials for power generation or heating to achieve sustainable use of energy.
440V 415V Garment Shredder Waste Fabric Shredder Machine Customized
Product Application

440V 415V Garment Shredder Waste Fabric Shredder Machine Customized

440V 415V Garment Shredder Waste Fabric Shredder Machine Customized
Successful Project
440V 415V Garment Shredder Waste Fabric Shredder Machine Customized
The process flow of preparing RDF (waste-derived fuel) through resource processing of waste textiles, cloth, leather, etc.:
‌1, Pretreatment and transportation ‌
‌Waste textiles enter the processing line through a chain conveyor or a belt conveyor to achieve automatic loading.
‌2, Coarse crushing ‌ ‌
The material is coarsely crushed by a double-shaft shredder or an industrial waste crusher to reduce the large volume of material to a size suitable for subsequent processing.
‌3, Sorting and purification ‌ ‌
Magnetic separation ‌: Separate ferromagnetic metal impurities and recover metal resources.
‌Wind separation ‌: Use airflow to separate light combustibles (such as fabrics and plastics) from heavy impurities (such as sand and gravel).
‌4. Fine crushing‌
The sorted combustibles enter the fine shredder and are further crushed into uniform particles of 50-100mm to meet the size requirements of RDF fuel.
5. Molding (optional)‌
Some processes will add an RDF molding machine to compress the crushed materials into high-density particles or fuel rods for easy transportation and storage.
6. Finished product application‌
The final RDF fuel can be directly used in cement kilns, power plants, etc. to replace coal and realize energy utilization.

440V 415V Garment Shredder Waste Fabric Shredder Machine Customized
