Specifications
Brand Name :
Xrido
Model Number :
Customizable
Certification :
CE ISO TUV
Payment Terms :
Negotiable
Delivery Time :
2-30 Working Days
place of origin :
Henan, China
brand name :
Xrido
model number :
AITE-AI
type :
Refuse Collector, AI Sorting Machine solid waste sorting machine
warranty :
1 Year
machinery test report :
Provided
video outgoing-inspection :
Provided
core components :
Pressure vessel, motor, Bearing, Gear, PLC, Pump, Engine
Product name :
Robotic Arm Sorting Platform
Application :
Household waste city garbage construction waste various solid garbage
After Warranty Service :
Field Maintenance
Advantage :
Easy Operation High Efficiency
Separation rate :
70-90%
Bag break rate (%) :
60-90%
Production Capacity :
20-100(t/h)(Customized), ≥20T/H
Voltage :
380V(can customized)
Condition :
New
Showroom Location :
None
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Applicable Industries :
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Construction works , Energy & Mining, Other
Description

Optical Separator Optical Sorting Machine Automatic MSW Segregation Machine Robotic Arm Sorting Plant

Products Description
Optical sorting machine, also known as light sorting machine, is an automated equipment that integrates modern advanced technology and realizes accurate material sorting based on the differences in material light reflection, absorption, transmission and other characteristics. It uses detection, sensing, artificial intelligence and other technologies to quickly identify the physical characteristics of materials and achieve efficient separation of materials and waste.

Optical Separator Optical Sorting Machine Automatic MSW Segregation Machine Robotic Arm Sorting Plant

Working principle of optical sorting machine:
Its working principle is to detect materials using the absorption, reflection and transmission phenomena generated when ultraviolet rays, visible light, infrared rays, etc. come into contact with objects. When the raw materials enter the equipment through the conveyor belt, the spectral sensor located above the conveyor belt quickly scans the materials and analyzes their size, color, material and other characteristics. If the material characteristics are consistent with the preset sorting standards, the information will be transmitted to the sorting unit, triggering the solenoid valve to release high-pressure airflow, blowing the target material off the original track, and collected by the subsequent conveyor belt; materials that do not meet the conditions will continue to be transported along the original track.

Optical Separator Optical Sorting Machine Automatic MSW Segregation Machine Robotic Arm Sorting Plant

Optical sorting machine has many advantages and characteristics. In terms of efficiency, it can quickly remove a large amount of useless materials and improve the overall processing efficiency; in terms of economy, the main energy consumption is electricity consumption, and compared with traditional processing methods, the operating cost is lower; it is environmentally friendly and pollution-free throughout the process, which is in line with the concept of green development; it has significant technological advancement, and with the development of computer and artificial intelligence technology, the level of intelligence is constantly improving, and it can adapt to the sorting of complex materials; its wide application allows it to process a variety of materials such as ore, wood, glass, plastic bottles, etc.; in terms of safety, it does not require chemical agents during operation, avoiding chemical safety risks.


Optical Sorting Recycling Line Product Parameters
Model
AITE-100D
AITE-200D
AITE-400D
Raw materials
Domestic Waste, Urban trash , Landfill Stale Waste, Municipal Solid Waste, Construction and Decoration Waste, Scrap Metal, Industrial Waste, Plastic Waste, Solid Waste
Capacity
100T/D
200T/D
400T/D
Power
149KW
224.7KW
279KW
Area
2400㎡
2800㎡
3000㎡
Working time
20 hours
20 hours
20 hours

Optical Sorting Plant Product Application
Its mainly used to the household waste, construction waste, waste metal, mine industry, power plant, metallurgy etc.
Optical Separator Optical Sorting Machine Automatic MSW Segregation Machine Robotic Arm Sorting Plant
Optical Separator Optical Sorting Machine Automatic MSW Segregation Machine Robotic Arm Sorting Plant
Our Advantages
Optical Separator Optical Sorting Machine Automatic MSW Segregation Machine Robotic Arm Sorting Plant
About Optical Sorting Plant:
Our automatic waste segregation machine garbage sorter construction waste sorting equipment can separate the waste fabrics, plastic bags and other sundries in the recycled aggregate of decoration waste, and can also clear out the large and medium-sized wooden blocks and plastic stool wastes. After two screenings, the impurity separation rate reached 98%.
