Specifications
Brand Name :
Xrido
Model Number :
Customizable
Certification :
CE ISO TUV
Payment Terms :
Negotiable
Delivery Time :
2-30 Working Days
place of origin :
Henan, China
type :
Refuse Collector
warranty :
1 Year
material :
Export Wooden Packing
machinery test report :
Provided
video outgoing-inspection :
Provided
core components :
Pressure vessel, motor, Bearing, Gear, PLC, Pump, Engine
Power :
Custom
Product name :
Refuse Derived Fuel RDF Briquette Press Machine
Application :
Recycling and Utilization of Waste Wood
After Warranty Service :
Field Maintenance
Advantage :
Easy Operation High Efficiency
Briquette size :
8-75mm
Usage :
Make Fuel Briquettes
Production Capacity :
100%
Voltage :
Country Voltage
Description
Wooden Sawdust Briquette Making Machine Fabric Cardboard Clothes Plastic Rdf Cube Sawdust Pallet Briquetting Machine
Products Description
The combustible briquetting machine is a special equipment that compresses various combustible wastes or biomass raw materials into high-density fuel blocks through mechanical pressure. The core purpose is to convert loose, low-energy-density combustibles into molded fuels (such as biomass pellets, RDF fuel blocks, etc.) that are easy to transport, store and burn efficiently.
RDF Briquette Press Machine for Wood Sawdust and Plastic Waste

RDF Briquette Press Machine for Wood Sawdust and Plastic Waste

Product Features
Refuse-derived fuel (RDF) technology is a technology that crushes and sorts domestic and industrial waste to remove non-combustible materials such as metals, glass, and sand from the garbage. After crushing and drying the combustible materials in the garbage (such as plastics, fibers, rubber, wood, food waste, etc.), additives are added, and densely molded to finally make solid fuel.
Model
Power(KW)
Number of ring die holes
Capacity(t/h)
Dimensions(mm)
YDRK-54
90
54
1.5-2.5
2200×1100×1700
YDRK-72
132
72
3-4
3230×2200×2000
YDRK-120
185
120
4-5
4055×2836×2380

Applicable raw material range​
The raw materials of the combustible briquetting machine must have a certain degree of combustibility (low calorific value is usually ≥3000kcal/kg), and common types include:

​Agricultural and forestry waste: straw (corn stalks, wheat stalks, rice stalks), rice husks, wood chips, sawdust, fruit tree branches, bark, sugarcane bagasse, etc.;
​Industrial organic waste: wine lees, medicine residues, papermaking black liquor residues, food processing waste residues (such as fruit shells, fruit cores), textile waste fibers, etc.;
​Domestic organic waste: kitchen waste (needs pretreatment dehydration, impurity removal), peels, fallen leaves, etc. (needs to control the impurity content to avoid corrosion of equipment);
​Low-grade fuel: some coal gangue, oil shale (needs to be crushed to a suitable particle size and then briquette to improve combustion efficiency).

Product Application

RDF Briquette Press Machine for Wood Sawdust and Plastic Waste

RDF Briquette Press Machine for Wood Sawdust and Plastic Waste
RDF Briquette Press Machine for Wood Sawdust and Plastic Waste
RDF Briquette Press Machine for Wood Sawdust and Plastic Waste

Waste to Biomass/RDF/SRF/TDF Briquette System:

The solid waste disposal system can be customized according to the actual materials.

RDF Briquette Press Machine for Wood Sawdust and Plastic Waste

RDF Briquette Press Machine for Wood Sawdust and Plastic Waste
MSW to RDF briquette Plant Industrial Waste to RDF briquette Plant

RDF Briquette Press Machine for Wood Sawdust and Plastic Waste

RDF Briquette Press Machine for Wood Sawdust and Plastic Waste
Biomass pellet/briquette Plant Waste Tire Disposal System
