5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM
5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM
5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM
5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM
5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM
5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM
Specifications
Place of Origin :
China
Brand Name :
HSM
Model Number :
1050,1060,3003, 3A21,5052.5005.5083.5A05,6061
MOQ :
500kg
Price :
USD2.0 - 3.5 per kg
Packaging Details :
Export standard packing or according to customer requirements
Delivery Time :
5-7 days
Payment Terms :
L/C , T/T
Supply Ability :
3500 Tons Per Month
Name :
prepainted color coated aluminum coils and sheets
Application :
Aluminum plastic panel, honeycomb panel, thermal insulation panel, aluminum curtain wall, shutter, shutter window,
Width :
0-1550mm, 20-2400mm, 25-130mm, From 650- 1250 mm, 10mm-2550mm
Grade :
3003 5052 5083 6061 7075 ETC
Surface Treatment :
Coated
Temper :
O - H112
Price term :
CIF CFR FOB Ex-Work, CIF, etc, EXW, FOB
Type :
Coil\plate\Roll, Steel Coil
Description

3003 5052 5083 6061 7075prepainted Color Coated Aluminum Coils And Sheets Color Coated Aluminum Coil

Overview

Color coated aluminum rolls are widely used in aluminum plastic plate, honeycomb plate, insulation board, aluminum curtain wall, shutter, shutter window, aluminum magnesium manganese roof system, aluminum ceiling, household appliances, downspout, aluminum cans and many other fields.

Product prepainted color coated aluminum coils and sheets
Property Anti-Corrosion,Heat Resistant
Surface Color Coated Coil
Production Process Cold Rolled,Hot Rolled
Internal Diameter 300mm,405mm,505mm or per request
Temper O,H14,H24,H32,H112 Etc;T4,T651 Etc
Thickness 0.3mm - 60mm
Width 600mm - 2600mm
Coil Weight 2-4 tons
MOQ 7 tons(According to specifications)
Payment Term TT,LC,WestUnion
Package Export wooden pallets,craft paper,anti-blushing agent.
Delivery Time Future goods:15-20 Work days,Ready Stock:7-10 days.
Quality of Material Totally free from defects like white rust,roll marks,adge damage,camber,dents,holes,break lines,scratches and free from coil set.
Kind Attention Specification can be custommized as the customer's requirements.

Product display

Mechanical Property
ALUMINUMALLOY Grade NormalTemper Temper Tensile StrengthN/mm² Yield StrengthN/mm² Elongation% Brinell HardnessHB
Plate Bar
1XXX 1050 O,H112,H O 78 34 40 - 20
1060 O,H112,H O 70 30 43 - 19
Al-Cu(2XXX) 2019 O,T3,T4,T6,T8 T851 450 350 10 - -
2024 O,T4 T4 470 325 20 17 120
Al-Mn(3XXX) 3003 O,H112,H O 110 40 30 37 28
3004 O,H112,H O 180 70 20 22 45
Al-Si (4XXX) 4032 O,T6,T62 T6 380 315 - 9 120
Al-Mg(5XXX) 5052 O,H112,H H34 260 215 10 12 68
5083 O,H112,H O 290 145 - 20 -
Al-Mg-Si(6XXX) 6061 O,T4,T6,T8 T6 310 275 12 15 95
6063 O,T1,T5,T6,T8 T5 185 145 12 - 60
Al-Zn-Mg(7XXX) 7003 T5 T5 315 255 15 - 85
7075 O,T6 T6 570 505 11 9 150

5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM

Packaging & Shipping

Stable delivery time

If products is stock , about 7-10days can delivery after received deposit.

If custom products , 100tons about 20-25days , exceed 100tons within 300tons about 40-50days , exceed 300tons, within 60days .

Product packaging material selection, good protection products

The uncoated aluminum plates are separated by paper to prevent static electricity from damaging the surface.

The innermost is wrapped in kraft paper, waterproof plastic paper is added on the outer, and the edge is protected by a carton corner.

The trays are fumigation trays or non-fumigation trays, one trays weight about 3-4 tons.

5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM

Company Information

We will always endeavor to be a more competitive and dynamic company in order to respond appropriately to increasingly sophisticated and diverse customer requirements, and to provide superior value-added products through our innovation.

We will proactively engage in R& D activities to further improve of our product reliability and performance.

HaoSiMai has secured a competitive edge in the development of non-ferrous metal production and processing technology based on high-capacity demand in the machinery and electricity industries and has grown continuously by producing multi-roval drawing products copper bus bars for ultra-high-pressure circuit breakers and aluminum sleeve products.

Continue design, understanding, technology and research and development of accurate specifications and reliability of parts.

5083 6061 7075 Pre Painted Aluminum Coils Color Coated Aluminium Sheet OEM ODM

Frequently Asked questions

Q1 . Can I have a sample order for products ?
A : Yes , we welcome sample order to test and check quality . Mixed samples are acceptable .


Q2 . What about the lead time ?
A : Sample needs 3-5 days


Q3 . Do you have any MOQ limit for products order ?
A : Low MOQ , 1pcs for sample checking is available


Q4 . How do you ship the goods and how long does it take to arrive ?
A : We usually ship by DHL , UPS , Fedex or TNT . It usually takes 3-5 days to arrive . Airline and seashipping also optional For mass products , ship freight is prefered


Q5 . Is it OK to print my logo on products ?
A : Yes , OEM and ODM are available for us


Q6 : How to ensure the quality ?
A Mill Test Certificate is supplied with shipment . If needed , a Third Party Inspection is acceptable
