Hydraulic Punching Grain Silo Panel Roll Forming Machine Custom Bending
Hydraulic Punching Grain Silo Panel Roll Forming Machine Custom Bending
Hydraulic Punching Grain Silo Panel Roll Forming Machine Custom Bending
Hydraulic Punching Grain Silo Panel Roll Forming Machine Custom Bending
Specifications
Brand Name :
METALIGN
Model Number :
SSP
Certification :
CE,ISO,etc
Place of Origin :
CHINA
MOQ :
1 set
Price :
Based on customization.
Payment Terms :
L/C,T/T
Supply Ability :
30 sets per month
Delivery Time :
30 days
Packaging Details :
Industrial plastic film wrapping, secured with steel wire.
Product name :
Cost-Effective Roll Former for Galvanized Steel Silo Panels Featuring Manual Decoiler and Precision Cutting
Key words :
Silo Panel/Roll Forming Machine/Metal Grain Silo Panel
Profile :
Grain Silo Roof Panels
Application :
Grain Storage / Metal Grain Silo Construction / Agricultural Warehouses / Industrial Silo Panels
Material type :
Galvanized steel
Material thickness :
3-5mm
Production speed :
15m/min
Main motor power :
30Kw
Forming stations :
22
Driving system :
Gearbox driving system
Frame structure :
Cast iron stands
Shaft diameter :
110mm
Machine condition :
Brand new
Shaft material :
#45 steel quenched 55-60℃
Roller material :
High grade #45 steel , surface with hard chrome
Display language :
English/Spanish/Russian/French,etc, customizable
Control technique :
PLC+Touch Screen
Delivery time :
30 days
Description

High-Efficiency Roll Forming Machine for Grain Silo Panels with Hydraulic Punching and Custom Bending

These introductions refer only to the production line and configuration shown in the main image. Each machine is custom-built. Metalign welcomes your inquiry and provides the right production line—forming metal into profiles aligned to your needs.

1. Production Line Overview

  • This production line is ideal for the metal silo panel industry, providing high precision forming and customization options. It caters to agricultural and industrial sectors, offering efficient, cost-effective, and versatile manufacturing for silo panels with various material thicknesses and shapes.

2. Profile Description

  • This profile is made from 3-4mm thick galvanized steel, offering durability and corrosion resistance. The shape is a specific metal panel for grain silos, featuring a high-precision design. It is primarily used in agricultural storage and industrial silo construction for strong, weather-resistant applications.

3. Production Process

  • Manual Decoiler → Leveling → Edge Trimming → Roll Former → Automatic Punching → Bending Machine → Hydraulic Cutter

  • The process begins with manual decoiling and independent leveling of the steel. Edge trimming ensures precise material width. The roll former then shapes the metal into the designated panel profile. Automatic punching follows the rolling process, and then the panels are bent. Finally, the hydraulic cutter trims the panels to the required length.

4. Technical Parameters

Machine Analysis
Manual Decoiler Used for uncoiling steel, manual operation ensures flexibility and control in steel handling.
Independent Leveling Machine Provides separate leveling, improving panel quality and forming precision.
Edge Trimming Ensures consistent steel width, reduces waste by trimming edges before forming.
Roll Former Forms metal into specific profiles, ensuring high precision and strong panel structure.
Automatic Punching Machine Tracks the forming speed, punches holes automatically without interrupting the production.
Bending Machine Adjustable for different bending angles, ensures versatility for various panel sizes.
Hydraulic Cutter Provides precise and clean cuts, ensuring accurate final product dimensions.

5. Key Focus

  • High Efficiency: The integration of tracking hydraulic punching ensures continuous, uninterrupted production.
  • Custom Bending: The bending machine is adjustable, providing flexibility for varying panel designs.
  • Cost-Efficiency: Edge trimming within the line reduces the need for separate slitting operations, optimizing material usage.

6. Production Line Components

Machine Name Quantity
Decoiler 1 set
Independent Leveling Machine 1 set
Edge Trimming 1 set
Roll Former 1 set
Hydraulic Punching Machine 1 set
Bending Machine 1 set
Hydraulic Cutter 1 set
PLC Cabinet 1 set
Hydraulic Station 2 sets
Out Table 2 sets

7. Customization Options

  • We offer flexible configurations for this production line to suit specific silo panel needs. Customization options include variations in punching patterns, panel lengths, bending angles, and specific roll forming die sets. The line can also be adapted for different material types or thicknesses, ensuring versatile production capabilities for various agricultural and industrial applications.
