Specifications
Brand Name :
DB
Model Number :
YX49-334-1000
Certification :
ISO SGS CE
Place of Origin :
Jiangsu, China
MOQ :
1 Set
Price :
US $15,000 - 40,000 / Set
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
20 Sets/Month
Delivery Time :
30 to 50 days after receiving the deposit
Packaging Details :
nude package in 40 GP Container
raw material :
galvalised steel sheet
Description


CE Certificated Metal Deck Roll Forming Machine with PLC Panasonic Control

Brief Introduction
The Roof Panels made by our Roll Forming Machine have beautiful appearance and bright color.
They are widely used in gardens, factories, resorts, hotels, exhibition halls, vacationlands,
ancient architectures and modern villas.

Working Flow of Roll Forming Machine
Decoiling the sheet-Sheet guiding-Roll forming-Measure length-Cutting the panel-Panels to the supporter

Gardens Knudson Roll Former , Q235 Roof Panel Roll Forming Machine

Technical Detail

A. General

Suitable Material Q235 or equivalent
Material Thickness 0.2-0.6 mm

Length of
the Sheet

You can set the length according to your need.
It is controlled by PLC
which can ensure the accuracy of ±1mm.
Cutting

Automatically stop and cutting when it comes to the set
length.


B. Components Details

Roller Material High grade 45# steel. Hard chrome plating, 0.05mm.
Main Frame 350# steel. More stable and no shaking.
Middle Plate

16mm. We use thicker plates to ensure stability
of our products.
Forming Steps 11-16, according to the drawing.
Shaft Material Φ70 mm, high grade 45# steel.

Treating process: tempering- finish turning,
high rigidity, hard to deform.

Cutting
Blade Material

 Cr12, hardness HRC60-62.
Treating process: heat treatment- plane abrasion- wire electrode cutting.

C. Electric Components

Suitable Power 380V, 50 Hz, 3 phase or according to your need.
Screen 7 inch touch screen, easy to operate.
PLC Delta DVP14ES

Well-adapted to various conditions, such as moisture,
electromagnetic disturbance.
Frequency Converter

Delta VFD-M. It has the advantage of slowing down before cutting,
to ensure the length accuracy (±1mm,
far better than industrial standard ±3mm).

Length
Measurement Device

 Omron, made in Japan.
It features with high accuracy and stability.



Pictures to Refer

Gardens Knudson Roll Former , Q235 Roof Panel Roll Forming Machine

Gardens Knudson Roll Former , Q235 Roof Panel Roll Forming Machine

Certificates

Gardens Knudson Roll Former , Q235 Roof Panel Roll Forming Machine
Company Scene

Gardens Knudson Roll Former , Q235 Roof Panel Roll Forming Machine


Guarantee:
1. Engineer will give free training lessons to labors in buyer’s factory.
2. The Buyer will buy the round-trip air ticket for Engineer if visa application is approved. The buyer is also responsible to bear expenses generated, e.g. visa formalities, meals, accommodation and allowance of USD80 per day per engineer.
3. During this guarantee period, we will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, we will provide the buyer spare parts at cost price.
4. We will charge the buyer cost price of spare parts beyond one year and provide long-term technical guide.
