VMPET/Al Foil Roll For Floor Heat Reflective Film Composite Film For Building
VMPET/Al Foil Roll For Floor Heat Reflective Film Composite Film For Building
VMPET/Al Foil Roll For Floor Heat Reflective Film Composite Film For Building
VMPET/Al Foil Roll For Floor Heat Reflective Film Composite Film For Building
VMPET/Al Foil Roll For Floor Heat Reflective Film Composite Film For Building
VMPET/Al Foil Roll For Floor Heat Reflective Film Composite Film For Building
VMPET/Al Foil Roll For Floor Heat Reflective Film Composite Film For Building
VMPET/Al Foil Roll For Floor Heat Reflective Film Composite Film For Building
Specifications
Brand Name :
BM
Model Number :
BM02
Certification :
ISO
Place of Origin :
CHINA
MOQ :
3tons
Price :
1.1-2.2usd/kg
Payment Terms :
T/T
Supply Ability :
600tons/monthly
Delivery Time :
7-10days
Packaging Details :
1.bubble film, to protect from collision during transportation 2.specified label, factory label or customized label without factory information 3.different types of packing ways according to roll size or customer's request 4.Standup pallet, Suspenderd pall
Material :
vmpet+pe
Hardness :
hard
Thickness :
customized ，10mic+100mic
Roll length :
4000m，5000m etc
Application :
Applications: orchard, packaging, building, printing, Agriculture, etc.
width :
900mm, 1050mm, 1250mm, etc
wrinkle :
Slightly Inconsistent Wrinkle Is Allowed
hs :
3920109090
Processing type :
Multiple Extrusion
Description

vmpet12mic+85mic pe / 8mic vmpet+6mic pe metalized film for construction and under floor construction

VMPET/AL+PE

1.Reflective to sunshine and solar heat
2.Water proof & damp-proof
3.To laminated with Woven,bubble and EPE,XPEfoam as thermal lnsulating materials,
4.Prevent dust and moisture from penetrating inside
5.Durable, environmentally friendly.
6.Building insulation materials

Metallized PET/Aluminum Foil coated PE film is a barrier film formed by depositing a thin layer of aluminum atoms onto high-quality PET film by vacuum aluminum plating process. It has bright metal gloss, excellent gas and light barrier and good moisture-proof,heat-resistant and puncture resistance. It can replace aluminum foil and other advantages.

Thickness of the films
  • Aluminum foil: 6.5mic,7mic,9mic,10mic,12mic etc.
  • Metallized PET film:8mic,10mic,12mic etc.
  • LDPE coating:4-30mic


Specification

Metallized PET film + PE

Type of material Multi layered coated film
Short name Metallized PET + PE Film
Metallization Inside
Thickness The nominal thickness is determined by the total thickness of the materials:
(6-12 mic) Metallized PET film + (6-25 mic) PE.
The total thickness of the material: ≤ 35 mic
Finalproduct Roll
Reel Heat-sealing layer (PE) inside
Materialwidth 400 - 2200 mm
NET weight (Min) 55 kg
(Max) 70 kg
WidthTolerance -2 mm / +2mm
Lateral Edges Alignment -2 mm / +2mm
Thickness Tolerance 6%
Splice unit/roll ≤ 1
type
Metallized PET / BOPET / Transparent OPP tape

Scotch width ≥ 40 mm
Splicemarking not necessary
ID ID material paper
Internal diameter 76 mm (3 inches)
ID material thickness 12 ÷ 15 mm
ID width Material width (0+5) mm
pecification
Thickness
Proportion
Specific Area
gr/m2
m2/kg
Alu7+PET12
20micron
36
28
Alu7+PET12+Alu7
30micron
58
17
Alu7+PET15
24micron
39
25
Alu9+PET12
23micron
43
23
Alu9+PET15
26micron
48
21
Alu9+PET19
30micron
54
19
Alu9+PET23
34micron
60
17
Alu9+PET12+Alu9
35micron
70
14
Alu9+PET23+Alu9
47micron
87
11.5
Alu12+PET12
26micron
52
19
Alu25+PET23
50micron
102
10
Alu25+PET12+Alu25
68micron
159
6.5
Alu40+PET12
54micron
127
8
Alu40+PET23
65micron
143
7
Alu40+PET36
78micron
161
6
Alu50+PET12
65micron
155
6.5
Alu50+PET23
76micron
170
6
Alu50+PET36
89micron
189
5.5

Application

1.Building insulation material composite
VMPET FILM laminate with insulation materials like Bubble,Woven,Foam,Non-woven for building insulation and cold chain which can increase thermal insulation performance
2.Packaging material
VMPET FILM laminate with other plastic film like OPP/MPET/PE,PET/VMPET/PE used for packaging that can prevent moisture and oxygen .
3.Electronic packaging
VMPET FILM used for packaging electronic devices to block static electricity.
4.Balloon decoration
VMPET FILM can be used for balloon.
5.Flexadux material
VMPET FILM used for air duct has heat insulation effect.
6.Agricultural use of membrane
VMCPP FILM used for agriculture can increase reflective and promote plants growth .


Our main products include

1.Transparent film,like CPP,CPE,OPP,BOPP,PE,PEM film
2.Metallized film, like VMPET,VMCPP film
3.Lamination film, like metallized PET film coating PE .
Packaging Details

1.bubble film, to protect from collision during transportation
2.specified label, factory label or customized label without factory information
3.different types of packing ways according to roll size or customer's request
4.Standup pallet, Suspenderd pallet
