High Precision 4 zones scanner metal detector Walk Through for Factory safe
High Precision 4 zones scanner metal detector Walk Through for Factory safe
High Precision 4 zones scanner metal detector Walk Through for Factory safe
High Precision 4 zones scanner metal detector Walk Through for Factory safe
High Precision 4 zones scanner metal detector Walk Through for Factory safe
High Precision 4 zones scanner metal detector Walk Through for Factory safe
Specifications
Brand Name :
Zhonganxie
Model Number :
TD-800
Certification :
CE, FCC, ROHS
Place of Origin :
China
MOQ :
1pc
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
10000pcs per month
Delivery Time :
5-7 working days
Packaging Details :
Carton boxes or according customer's need
Gross weight :
64KG
Working voltage :
90V~240V 50/60Hz
Each zone sensitivity :
1-200 level
Security level :
1-20
Working frequency range :
1-50 bands
Description

High Precision 4 zones scanner metal detector Walk Through for Factory safe

Features

  1. visible alarm simultaneously to ascertain layout of metal articles
  2. Count passengers and alarm times automatically
  3. Password protection and only authorized person can operate
  4. Nice for use at building entrances, malls, airports and market or factory entries
  5. Developed to stand external climatic conditions and are suitable for single zone and multi-zone door frame detector
  6. ensitive control knob for precise setting at desired levels
  7. Inspection rate: 1 person/second
  8. Detection zones: 4 zones
  9. Easy to assemble using instruction manuals

  10. Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity

  11. Sensitivity adjustable, three patterns such as high, middle and low for various requirements

Specification

Model Number TD-800
Technical Parameters
Vertical dimension 2230x580x850mm
Vertical channel size 2000x700mm
Main box packing size 755x340x210mm
Detection door packing size 2290x630x190mm
Net weight of main box/detection door 56.6KG
Gross weight of main box/detection door 62.8KG
Working voltage 90V~240V 50/60Hz
Power consumption 20W
Working frequency range 1-50 bands
Working environment temperature -20℃ ~ 65℃
Installation environment (W) 100cm* (L) 200cm
(minimum range without metal)

Our Services:

  • Professional reply for your question in time during Monday to Saturday 24 hours.
  • All of our product already get pass the aging test, to ensure reliability of using.
  • Quality inspection department will check the machine again before packing
  • Accept your engineer come to our factory for training in free

Our advantages

  1. Brands cooperation,ODM,OEM
  2. Product design, technology development, parts processing and sales integration services
  3. Sales of a complete set of technical solutions
  4. Technical guidance and training
  5. One of the world's top four brands, leading technology, quality first, service first-class
  6. Twenty-four hours service
